Especificações Técnicas

SPECIFICATIONS   STANDARDS IEEE 802.3-2008 USB 3.0 DATA RATE USB 3.0 (TYPE-A CONNECTOR): 625MBPS (5000MBPS) FIBER: 125MBPS (1000MBPS) FIBER PORT 1000BASE-SX SC OR LC 100/1000BASE-X SFP MAX FRAME SIZE 1518 BYTES (UNTAGGED) STATUS LEDS USB: SPEED / ACTIVITY GREEN: ON – USB 3.0 YELLOW: ON – USB 2.0 GREEN & YELLOW: OFF – USB DOWN FIBER: SPEED / ACTIVITY GREEN – LINK @ 1000MBPS, YELLOW – LINK @ 100MBPS, FLASHING – ACTIVITY SOFTWARE SUPPORT WINDOWS 7, 8, 8.1, 10, LINUX, AND MACINTOSH 10.6 TO 10.11 DIMENSIONS WIDTH: 2.09” [56 MM] DEPTH: 12.25 [233 MM] HEIGHT: 1 [20 MM] POWER CONSUMPTION 2.1 WATTS (LC: TYPICAL) 2.18 WATTS (SC: TYPICAL) 3.15 WATTS MAX (SFP: MSA COMPLIANT SUPPORTING UP TO A 1 WATT MODULE) POWER SOURCE USB BUS ENVIRONMENT OPERATING: 0°C TO 50°C STORAGE: -20°C TO +80°C HUMIDITY: 5% TO 95% (NON-CONDENSING) ALTITUDE: 0 – 10,000 FT. (WITH DERATING) WEIGHT 0.35 LBS. [0.16 KG] COMPLIANCE EN55032 CLASS A, EN55024, FCC PART 15, SUBPART B, CLASS A, CE MARK TN-USB3-SX-01 TRANSITION NETWORKS USB 3.0 TO ETHERNET TAGS DE TN-USB3-SX-01: TN-USB3-SX-01, TNUSB3SX01, TRANSITION TN-USB3-SX-01, USB PARA FIBRA OPTICA, USB FIBRE CHANEL, USB 3.0 PARA 1000 BASE-SX, ADAPTADOR USB PARA FIBRA, USB/FIBRECHANNEL
