Especificações Técnicas

PADRÕES E PROTOCOLOS IEEE 802.3I, IEEE 802.3U, IEEE 802.3AB, IEEE802.3Z, IEEE 802.3AD, IEEE 802.3X, IEEE 802.1D, IEEE 802.1S, IEEE 802.1W, IEEE 802.1Q, IEEE 802.1X, IEEE 802.1P INTERFACE 24 10/100MBPS RJ45 PORTS (AUTO NEGOTIATION/AUTO MDI/MDIX) 4 10/100/1000MBPS RJ45 PORTS (AUTO NEGOTIATION/AUTO MDI/MDIX) 4 COMBO GIGABIT SFP PORTS 1 CONSOLE PORT MÍDIA DE REDE 10BASE-T: UTP CATEGORY 3, 4, 5 CABLE (MAXIMUM 100M) EIA/TIA-568 100STP (MAXIMUM 100M) 100BASE-TX/1000BASE-T: UTP CATEGORY 5, 5E CABLE (MAXIMUM 100M) EIA/TIA-568 100STP (MAXIMUM 100M) 1000BASE-X: MMF, SMF QUANTIDADE DE VENTOINHAS FANLESS FONTE DE ALIMENTAÇÃO 100~240VAC, 50/60HZ CONSUMO DE ENERGIA MAXIMUM: 15W (220V/50HZ) DIMENSÕES (L X C X A) 17.3*7.1*1.7 IN.(440*180*44 MMDESEMPENHO EMPILHAMENTO 32 UNITS VIRTUAL STACKING LARGURA DE BANDA / BACKPLANE 12.8GBPS TAXA DE ENCAMINHAMENTO DE PACOTES 9.5MPPS TABELA DE ENDEREÇOS MAC 8K JUMBO FRAME 2048 BYTES CARACTERÍSTICAS DE SOFTWARE QOS 4 QUEUES/PORT 802.1P/IP DSCP BASED COS,TOS CARACTERÍSTICAS L2 IGMP SNOOPING: V1/V2/V3 802.3AD WITH LACP SPANNING TREE STP/RSTP/MSTP BPDU FILTERING/GUARD PORT MIRRORING FLOW CONTROL VLAN SUPPORTS UP TO 4K VLANS SIMULTANEOUSLY (OUT OF 4K VLAN IDS) PORT/ TAG-BASED/PRIVATE/PROTOCOL-BASED VLAN/ Q IN Q,GARP / GVRP LISTA DE CONTROLE DE ACESSO PACKET FLOW FILTER; PACKET FLOW REDIRECTION; TIME RANGE BASED; FLOW-BASED QOS SEGURANÇA IP-MAC-PORT-VID BINDING IEEE 802.1X (RADIUS):PORT/MAC BASED, VLAN ASSIGNMENT, GUEST VLAN, QOS ASSIGNMENT, SUPPLICANT SUPPORT DOS DEFENCE DYNAMIC ARP INSPECTION (DAI) SSH: V1/V2 SSL:V1.5/V2 PORT SECURITY BROADCAST STORM CONTROL GUEST VLAN IP SOURCE GUARD IPV6 DUAL IPV4/IPV6 STACK MULTICAST LISTENER DISCOVERY (MLD) SNOOPING IPV6 NEIGHBOR DISCOVERY (ND) PATH MAXIMUM TRANSMISSION UNIT (MTU) DISCOVERY INTERNET CONTROL MESSAGE PROTOCOL (ICMP) VERSION 6 TCPV6/UDPV6 APLICAÇÃO IPV6 DHCPV6 CLIENT PING6 TRACERT6 TELNET(V6) IPV6 SNMP IPV6 SSH IPV6 SSL HTTP/HTTPS IPV6 TFTP GERENCIAMENTO SYSTEM DIAGNOSE: VCT SNMP: V1/V2/V3 RMON: GROUP 1, 2, 3, 9 COMMAND LINE INTERFACE: TELNET/CONSOLE TIME SETTING: SNTP FIRMWARE UPGRADE: TFTP E WEB DGCO CLIENT TL-SL5428E TP-LINK SWITCH TL-SL5428E 24 + 4 PORTAS MAIORES DETALHES DE TL-SL5428E NO SITE DO FABRICANTE: HTTPS://WWW.TP-LINK.COM/BR/BUSINESS-NETWORKING/MANAGED-SWITCH/TL-SL5428E/#OVERVI TAGS DE TL-SL5428E: TL-SL5428E, TLSL5428E, TL SL5428E, SWITCH TP-LINK TL-SL5428E, SWITCH TPLINK TL-SL5428E, SWITCH TPLINK 24 PORTAS, SWITCH GIGA
