Especificações Técnicas

HARDWARE SPECIFICATIONS 10/100BASE-TX AUTO MDI/MDIX PORTS 8 LED INDICATORS 3 X LED FOR SYSTEM AND POWER GREEN: DC POWER 1 GREEN: DC POWER 2 GREEN: POWER FAULT 1X LED FOR EACH COPPER PORT GREEN: 10/100 LNK/ACT ENCLOSURE IP30-RATED METAL CASE DIMENSIONS (W X D X H) 135 X 87 X 32 MM WEIGHT 428G ESD PROTECTION 6KV DC EFT PROTECTION 6KV DC POWER REQUIREMENTS 12~48V DC, REDUNDANT POWER WITH POLARITY REVERSE PROTECTION , 24V AC POWER SUPPORT POWER CONSUMPTION/DISSIPATION 2.1 WATTS/7.1BTU INSTALLATION DIN RAIL KIT AND WALL-MOUNT EAR ALARM PROVIDES ONE RELAY OUTPUT FOR POWER FAILURE ALARM RELAY CURRENT CARRY ABILITY: 3A @ DC 30V CONNECTOR REMOVABLE 6-PIN TERMINAL BLOCK PIN 1/2 FOR POWER 1; PIN 3/4 FOR FAULT ALARM; PIN 5/6 FOR POWER 2 SWITCH SPECIFICATIONS SWITCH PROCESSING SCHEME STORE-AND-FORWARD ADDRESS TABLE 1K BUFFER MEMORY EMBEDDED 448K BITS PACKET BUFFER FLOW CONTROL BACK PRESSURE FOR HALF DUPLEX, IEEE 802.3X PAUSE FRAME FOR FULL DUPLEX SWITCH FABRIC 1.6GBPS THROUGHPUT (PACKET PER SECOND) 1.19MPPS NETWORK CABLES 10BASE-T: 2-PAIR UTP CAT. 3, 4, 5, UP TO 100 METERS 100BASE-TX: 2-PAIR UTP CAT. 5, 5E UP TO 100 METERS STANDARDS CONFORMANCE STANDARDS COMPLIANCE IEEE 802.3 ETHERNET IEEE 802.3U FAST ETHERNET IEEE 802.3X FULL DUPLEX FLOW CONTROL IEEE 802.3AZ ENERGY EFFICIENT ETHERNET TEMPERATURE OPERATING: -40~75 DEGREES C STORAGE: -40~75 DEGREES C HUMIDITY OPERATING: 5% TO 95%, STORAGE: 5% TO 95% (NON-CONDENSING) REGULATORY COMPLIANCE FCC PART 15 CLASS A, CE STABILITY TESTING IEC60068-2-32 (FREE FALL) IEC60068-2-27 (SHOCK-PROOF) IEC60068-2-6 (VIBRATION-PROOF) SW-801T PLANET SWITCH INDUSTRIAL 8 PORTAS 10/100TX TAGS DE SW-801T: SW-801T, SW801T, SW 801T, PLANET SW-801T, SWITCH PLANET IGS-801M, SWITCH PLANET INDUSTRIAL SW-801T, SWITCH INDUSTRIAL, SWITCH PLANET 8 PORTAS, INDUSTRIAL, PLANET TECHNOLOGY, SWITCH PLANET INDUSTRIAL
