Especificações Técnicas

TECHNOLOGY STANDARDS IEEE 802.3 FOR 10BASET IEEE 802.3U FOR 100BASET(X) IEEE 802.3X FOR FLOW CONTROL IEEE 802.3AF FOR POWER-OVER-ETHERNET PROCESSING TYPE STORE AND FORWARD FLOW CONTROL IEEE802.3X FLOW CONTROL, BACK PRESSURE FLOW CONTROL - INTERFACE M12 PORTS 10/100BASET(X) AUTO NEGOTIATION SPEED, F/H DUPLEX MODE AND AUTO MDI/MDI-X CONNECTION LED INDICATORS PWR, LNK/ACT, POE - POWER REQUIREMENTS INPUT VOLTAGE 48 VDC (46 TO 50 V) INPUT CURRENT TN-5308-4POE: 1.6 A @ 48 VDC TN-5308-8POE: 2.9 A @ 48 VDC OVERLOAD CURRENT PROTECTION 3 A @ 48 VDC CONNECTION M12 CONNECTOR REVERSE POLARITY PROTECTION PRESENT - POE (PER PORT) MAX. OUTPUT POWER 15.4 W OUTPUT VOLTAGE 44 TO 48.5 VDC MAX. OUTPUT CURRENT 350 MA MAX. OVERLOAD PROTECTION 400 MA - PHYSICAL CHARACTERISTICS HOUSING METAL, IP40 PROTECTION DIMENSIONS TN-5308-4POE: 60 X 216.6 X 48.7 MM (2.36 X 8.53 X 1.91 IN) TN-5308-8POE: 80 X 216.6 X 49.5 MM (3.15 X 8.53 X 1.95 IN) WEIGHT TN-5308-4POE: 675 G TN-5308-8POE: 970 G INSTALLATION PANEL MOUNTING, DIN-RAIL MOUNTING (WITH OPTIONAL KIT) - ENVIRONMENTAL LIMITS OPERATING TEMPERATURE STANDARD MODELS: -25 TO 60C (32 TO 140F) WIDE TEMP. MODELS: -40 TO 75C (-40 TO 167F) STORAGE TEMPERATURE -40 TO 85C (-40 TO 185F) AMBIENT RELATIVE HUMIDITY 5 TO 95% (NON-CONDENSING) - STANDARDS AND CERTIFICATIONS SAFETY UL 508 (PENDING) EMI FCC PART 15 SUBPART B CLASS A, EN 55022 CLASS A EMS EN 61000-4-2 (ESD) LEVEL 3, EN 61000-4-3 (RS) EXCEEDS LEVEL 3, EN 61000-4-4 (EFT) LEVEL 3, EN 61000-4-5 (SURGE) LEVEL 3, EN 61000-4-6 (CS) LEVEL 3, EN 61000-4-8, EN 61000-4-11 RAIL TRAFFIC (FOR PANEL MOUNTING INSTALLATIONS) EN 50155, EN 50121-4 SHOCK IEC 61373 FREEFALL IEC 60068-2-32 VIBRATION IEC 61373 NOTE PLEASE CHECK MOXA-S WEBSITE FOR THE MOST UP-TO-DATE CERTIFICATION STATUS. TN-5308-LV MOXA SWITCH ETHERNET 8 PORTAS M12 10/100BTX TAGS DE TN-5308-LV: TN-5308-LV, TN-5308-LV-T, MOXA TN-5308-LV-T, SWITCH MOXA TN-5308-LV-T, SWITCH MOXA 8 PORTAS M12, SWITCH M12, SWITCH M12 10/100, TN-5308, MOXA TN5308LVT, MOXA TN-5308, TN-5308-LV-T
