Especificações Técnicas

HARDWARE SPECIFICATIONS COPPER PORTS 8 X 10/100/1000BASE-T RJ45 AUTO-MDI/MDI-X PORTS SFP PORTS 2 X 100/1000BASE-X SFP INTERFACES SUPPORTS 100/1000MBPS DUAL MODE AND DDM POE INJECTOR PORT 8 PORTS WITH 802.3AT/AF POE INJECTOR WITH PORT-1 TO PORT-8 CONSOLE 1 X RS-232-TO-RJ45 SERIAL PORT (115200, 8, N, 1) RESET BUTTON > 5 SEC: FACTORY DEFAULT DIMENSIONS (W X D X H) 280 X 180 X 44 MM, 1U HEIGHT WEIGHT 1.6KG ENCLOSURE METAL POWER REQUIREMENTS AC 100~240V, 50/60HZ, 2.5A, AUTO-SENSING POWER CONSUMPTION/ DISSIPATION 170 WATTS (MAX.)/580BTU ESD PROTECTION CONTACT DISCHARGE 6KV DC AIR DISCHARGE 8KV DC FAN FANLESS DESIGN LED SYSTEM: -PWR X1 (GREEN) -SYS X1 (GREEN) PER POE PORT (PORT 1 TO PORT 8): -LNK/ACT X1 (GREEN) -POE-IN-USE X1 (ORANGE) PER GIGABIT SFP PORT (PORT 9 TO PORT 10): -100/1000 LNK/ACT X1 (GREEN) SWITCHING SPECIFICATIONS SWITCH ARCHITECTURE STORE-AND-FORWARD SWITCH FABRIC 20GBPS/NON-BLOCKING SWITCH THROUGHPUT@64BYTES 14.88MPPS ADDRESS TABLE 8K ENTRIES SHARED DATA BUFFER 4.1 MEGABITS FLOW CONTROL IEEE 802.3X PAUSE FRAME FOR FULL DUPLEX BACK PRESSURE FOR HALF DUPLEX JUMBO FRAME 10K BYTES POWER OVER ETHERNET POE STANDARD IEEE 802.3AF/802.3AT POE / PSE POE POWER SUPPLY TYPE END-SPAN POE POWER OUTPUT PER PORT 56V DC, 30 WATTS (MAX.) POWER PIN ASSIGNMENT 1/2( ), 3/6(-) POE POWER BUDGET 140 WATTS (MAX.) @ 25 DEGREES C 120 WATTS (MAX.) @ 50 DEGREES C NUMBER OF 802.3AF PDS 8 UNITS NUMBER OF 802.3AT PDS 5 UNITS POE MANAGEMENT PD ALIVE CHECK SCHEDULED POWER RECYCLING POE SCHEDULE POE USAGE MONITORING POE EXTENSION LAYER 2 FUNCTIONS PORT MIRRORING TX/RX/BOTH MANY-TO-1 MONITOR UP TO 4 SESSIONS VLAN IEEE 802.1Q TAGGED-BASED VLAN IEEE 802.1AD Q-IN-Q TUNNELING VOICE VLAN PROTOCOL VLAN PRIVATE VLAN (PROTECTED PORT) GVRP UP TO 256 VLAN GROUPS, OUT OF 4094 VLAN IDS LINK AGGREGATION IEEE 802.3AD LACP/STATIC TRUNK SUPPORTS1 TRUNK GROUPS WITH 2 PORTS PER TRUNK SPANNING TREE PROTOCOL STP, IEEE 802.1D SPANNING TREE PROTOCOL RSTP, IEEE 802.1W RAPID SPANNING TREE PROTOCOL MSTP, IEEE 802.1S MULTIPLE SPANNING TREE PROTOCOL STP BPDU GUARD, BPDU FILTERING AND BPDU FORWARDING IGMP SNOOPING IPV4 IGMP (V2/V3) SNOOPING IPV4 IGMP QUERIER UP TO 256 MULTICAST GROUPS MLD SNOOPING IPV6 MLD (V1/V2) SNOOPING UP TO 256 MULTICAST GROUPS QOS 8 MAPPING ID TO 8 LEVEL PRIORITY QUEUES -PORT NUMBER -802.1P PRIORITY -802.1Q VLAN TAG -DSCP FIELD IN IP PACKET TRAFFIC CLASSIFICATION BASED, STRICT PRIORITY AND WRR RING SUPPORTS ERPS, AND COMPLIES WITH ITU-T G.8032 SECURITY FUNCTIONS ACCESS CONTROL LIST IPV4/IPV6 IP-BASED ACL MAC-BASED ACL SECURITY IP-MAC PORT BINDING MAC FILTER STATIC MAC ADDRESS DHCP SNOOPING AND DHCP OPTION82 DOS ATTACK PREVENTION ARP INSPECTION IP SOURCE GUARD AAA BUILT-IN RADIUS CLIENT TO CO-OPERATE WITH RADIUS SERVER NETWORK ACCESS CONTROL IEEE 802.1X PORT-BASED AUTHENTICATION RADIUS/TACACS USER ACCESS AUTHENTICATION MANAGEMENT FUNCTIONS BASIC MANAGEMENT INTERFACES RS232 CONSOLE WEB BROWSER TELNET SNMP V1, V2C SECURE MANAGEMENT INTERFACES SSHV2, TLS V1.2, SNMP V3 SYSTEM MANAGEMENT FIRMWARE UPGRADE BY HTTP/TFTP PROTOCOL THROUGH ETHERNET NETWORK LLDP PROTOCOL SNTP PLANET SMART DISCOVERY UTILITY PLANET NMS SYSTEM EVENT MANAGEMENT REMOTE/LOCAL SYSLOG SYSTEM LOG SNMP MIBS RFC 1213 MIB-II RFC 1215 GENERIC TRAPS RFC 1493 BRIDGE MIB RFC 2674 BRIDGE MIB EXTENSIONS RFC 2737 ENTITY MIB (VERSION 2) RFC 2819 RMON (1, 2, 3, 9) RFC 2863 INTERFACE GROUP MIB RFC 3635 ETHERNET-LIKE MIB RFC 3621 POWER ETHERNET MIB STANDARDS CONFORMANCE REGULATORY COMPLIANCE FCC PART 15 CLASS A, CE STANDARDS COMPLIANCE IEEE 802.3 10BASE-T IEEE 802.3U 100BASE-TX/100BASE-FX IEEE 802.3Z GIGABIT SX/LX IEEE 802.3AB GIGABIT 1000T IEEE 802.3X FLOW CONTROL AND BACK PRESSURE IEEE 802.3AD PORT TRUNK WITH LACP IEEE 802.1D SPANNING TREE PROTOCOL IEEE 802.1W RAPID SPANNING TREE PROTOCOL IEEE 802.1S MULTIPLE SPANNING TREE PROTOCOL IEEE 802.1P CLASS OF SERVICE IEEE 802.1Q VLAN TAGGING IEEE 802.1X PORT AUTHENTICATION NETWORK CONTROL IEEE 802.1AB LLDP IEEE 802.3AF POWER OVER ETHERNET IEEE 802.3AT POWER OVER ETHERNET PLUS RFC 768 UDP RFC 793 TFTP RFC 791 IP RFC 792 ICMP RFC 2068 HTTP RFC 1112 IGMP VERSION 1 RFC 2236 IGMP VERSION 2 RFC 3376 IGMP VERSION 3 RFC 2710 MLD VERSION 1 RFC 3810 MLD VERSION 2 ITU G.8032 ERPS RING ENVIRONMENT OPERATING TEMPERATURE: 0 ~ 50 DEGREES C RELATIVE HUMIDITY: 5 ~ 95% (NON-CONDENSING) STORAGE TEMPERATURE: -20 ~ 70 DEGREES C RELATIVE HUMIDITY: 5 ~ 95% (NON-CONDENSING) GS-4210-8P2S PLANET SWITCH 8 PORTAS GIGABIT POE 802.3AT MAIORES DETALHES DE GS-4210-8P2S NO SITE DO FABRICANTE: HTTPS://WWW.PLANET.COM.TW/EN/PRODUCT/GS-4210-8P2S-V3 TAGS DE GS-4210-8P2S: GS-4210-8P2S, GS42108P2S, GS 4210 8P2S, SWITCH POE + SFP, SWITCH RACK DE 19, SWITCH PARA CAMERAS, SWITCH WEB SMART COM CAPACIDADE PARA FIBRA, ENTRADA 2 MINI-GBIC, SWITCH POE, HUB 8 PORTAS, SWITCH PLANET, MONITORAMENTO, PLANET TECHNOLOGY, GSD-802PS, GS-4210-8P-2S
