Especificações Técnicas

HARDWARE FEATURES STANDARDS AND PROTOCOLS IEEE 802.3I, IEEE 802.3U, IEEE 802.3AB, IEEE 802.3AF,  IEEE 802.3X, IEEE 802.1Q, IEEE 802.1P INTERFACE 8 10/100/1000MBPS RJ45 PORTS AUTO NEGOTIATION/AUTO MDI/MDIX NETWORK MEDIA 10BASE-T: UTP CATEGORY 3, 4, 5 CABLE (MAXIMUM 100M) EIA/TIA-568 100STP (MAXIMUM 100M) 100BASE-TX: UTP CATEGORY 5, 5E CABLE (MAXIMUM 100M) EIA/TIA-568 100STP (MAXIMUM 100M) 1000BASE-T: UTP CATEGORY 5, 5E, 6 OR ABOVE CABLE (MAXIMUM 100M) EIA/TIA-568 100STP (MAXIMUM 100M) FAN QUANTITY FANLESS POWER SUPPLY EXTERNAL POWER ADAPTER 100VAC ~ 240VAC (OUTPUT: 48VDC / 1.25A) POE PORTS(RJ45) POE PORTS (RJ45) STANDARD: 802.3 AF COMPLIANT POE PORTS: PORT 1PORT 4 POE POWER BUDGET: 55W MAX POWER CONSUMPTION 5.2W WITH NO POE DEVICE CONNECTED 65.2W WITH 55W POE DEVICES CONNECTED MAX HEAT DISSIPATION 17.6 BTU/H (WITH NO PD CONNECTED) 222.4 BTU/H (WITH 55W PD CONNECTED)   PERFORMANCE SWITCHING CAPACITY 16GBPS PACKET FORWARDING RATE 11.9MPPS MAC ADDRESS TABLE 4K PACKET BUFFER MEMORY 1.5MB JUMBO FRAME 15KB SOFTWARE FEATURES QUALITY OF SERVICE SUPPORT PORT-BASED/802.1P/DSCP PRIORITY SUPPORT 4 PRIORITY QUEUES RATE LIMIT STORM CONTROL L2 FEATURES IGMP SNOOPING V1/V2/V3 LINK AGGREGATION PORT MIRRORING CABLE DIAGNOSTICS LOOP PREVENTION VLAN SUPPORTS UP TO 32 VLANS SIMULTANEOUSLY (OUT OF 4K VLAN IDS) MTU/PORT/TAG VLAN MANAGEMENT WEB-BASED GUI EASY SMART CONFIGURATION UTILITY TRANSMISSION METHOD STORE-AND-FORWARD   OTHERS CERTIFICATION FCC, ROHS PACKAGE CONTENTS TL-SG108PE POWER ADAPTER INSTALLATION GUIDE RUBBER FEET ENVIRONMENT OPERATING TEMPERATURE: 0Â--~40Â-(32Â--~104Â--) STORAGE TEMPERATURE: -40Â--~70Â-(-40Â--~158Â--) OPERATING HUMIDITY: 10%~90%RH NON-CONDENSING STORAGE HUMIDITY: 5%~95%RH NON-CONDENSING TL-SG108PE TP-LINK SWITCH 8 PORTAS GIGABIT EASY POE TAGS DE TL-SG108PE: TL-SG108PE, TPLINK TL-SG108PE, TPLINK TLSG108PE, TPLINK POE, 8 PORTAS POE, SWITCH 8 PORTAS POE, SWTICH TP LINK POE

Informações Adicionais
