Especificações Técnicas

OUTPUT NOMINAL OUTPUT VOLTAGE 208V , 230V MAXIMUM TOTAL CURRENT DRAW 16 OUTPUT CONNECTIONS (8) IEC 320 C13 (BATTERY BACKUP) INPUT NOMINAL INPUT VOLTAGE 200V , 208V , 230V INPUT FREQUENCY 50/60 HZ INPUT CONNECTIONS IEC-320 C20 CORD LENGTH 8.2FT ( 2.5METERS ) ACCEPTABLE INPUT VOLTAGE 200-240VAC NUMBER OF POWER CORDS 1 LOAD CAPACITY 3680VA MAXIMUM INPUT CURRENT 20A REGULATORY DERATED INPUT CURRENT (NORTH AMERICA) 16A PHYSICAL MAXIMUM HEIGHT 1.73INCHES ( 44MM , 4.4CM ) MAXIMUM WIDTH 17.5INCHES ( 445MM , 44.5CM ) MAXIMUM DEPTH 4.25INCHES ( 108MM , 10.8CM ) RACK HEIGHT 1U NET WEIGHT 5.0LBS. ( 2.27KG ) SHIPPING WEIGHT 7.6LBS. ( 3.45KG ) SHIPPING HEIGHT 2.75INCHES ( 70MM , 7.0CM ) SHIPPING WIDTH 18.5INCHES ( 470MM , 47.0CM ) SHIPPING DEPTH 13.5INCHES ( 343MM , 34.3CM ) COLOR BLACK ENVIRONMENTAL OPERATING TEMPERATURE 32 113 °F ( 0 45 °C ) OPERATING RELATIVE HUMIDITY 0 95 % OPERATING ELEVATION 0-10000FT ( 0-3000METERS ) STORAGE TEMPERATURE -25 65 °C STORAGE RELATIVE HUMIDITY 0 95 % STORAGE ELEVATION 0-50000FT ( 0-15000METERS ) CONFORMANCE APPROVALS CUL LISTED, CE, CSA, EN 55022 CLASS A, EN 55024, EN 61000-3-2, EN 61000-3-3, GOST, IRAM, MIC, UL 60950, UL LISTED, VDE, VCCI   SUSTAINABLE OFFER STATUS ROHS COMPLIANT REACH REACH: CONTAINS NO SVHCS BATTERY DIRECTIVE COMPLIANT PROPOSITION 65 WARNING AVAILABLE IN DOCUMENTATION TAB AP7921B REGUA APC PDU 1U 8 TOMADAS 220V 16A C13 TAGS DE AP7921B: AP7921B, AP7921, AP 7921B, AP-7921B, REGUA APC, REGUA DE TOMADAS APC, RACK PDU 1U, PDU 1U, APC 1U, SWITCHED, APC SWITCHED, RACK APC, PDU COM COMUTADOR HORIZONTAL 1U 220V 16A ENT IEC C20 SAI 8 C13, PDU APC 8 TOMADAS

Informações Adicionais
