Especificações Técnicas

TECHNICAL SPECIFICATIONS PERFORMANCE - MAX THROUGHPUT: UP TO 1.0 GBPS IP (1.7 GBPS PHY) - CLIENT CAPACITY: 100 CLIENTS (WIFI INTEROP); 44 CLIENTS (SRS) - WIRELESS PROTOCOLS: WIFI INTEROP, SPECTRUM REUSE SYNCHRONIZATION (SRS) RADIO - MIMO E MODULATION: 4X4:4 MIMO OFDM UP TO 256-QAM - BANDWIDTH**: 20/40/80 MHZ CHANNELS - TUNABLE IN 5 MHZ INCREMENTS FOR GPS SYNC - TUNABLE TO STANDARD WIFI CHANNELS FOR WIFI INTEROP - FREQUENCY RANGE: - GPS SYNC: 4900-6400 MHZ* - WIFI INTEROP: 5170-5835 MHZ - RESTRICTED BY COUNTRY OF OPERATION (-NEW- US/FCC 5600-5650 SUPPORT) - MAX OUTPUT POWER: 30 DBM - SENSITIVITY (MCS 0): -87 DBM @ 80 MHZ -90 DBM @ 40 MHZ -93 DBM @ 20 MHZ POWER - MAX POWER CONSUMPTION: 25 W - SYSTEM POWER METHOD: 802.3AT COMPLIANT - POE POWER SUPPLY: PASSIVE POE COMPLIANT, 48-56 V POWER OVER ETHERNET SUPPLY WITH IEC61000-4-5 SURGE PROTECTION PHYSICAL - DIMENSIONS: HEIGHT: 300 MM (11.81-) WIDTH: 151 MM (12.40-) DEPTH: 85 MM (3.35-) - WEIGHT: 1.75 KG (3.86 LBS) - ENCLOSURE CHARACTERISTICS: OUTDOOR UV-STABILIZED ENGINEERED POLYMER WITH INTEGRATED MOUNTING PANEL - MOUNTING: DUAL-POLE STRAP MOUNT AND SLIP ON MOUNT FOR COMPARABLE ANTENNA - CONNECTOR TYPE: FEMALE TYPE N (X4) ENVIRONMENTAL - OUTDOOR INGRESS PROTECTION RATING: IP67 - OPERATING TEMPERATURE: -40°C TO 55°C (-40°F TO 131°F) - OPERATING HUMIDITY: 5 TO 100% CONDENSING - OPERATING ALTITUDE: 4,420 M (14,500-) MAXIMUM - SHOCK A5C MIMOSA ACCESS POINT A5C POINT-TO-MULTIPOINT TAGS DE A5C: A5C, MIMOSA A5C, ACESS POJNT A5C, ACCESS POINT MIMOSA A5C, MULTIPONTO, MULTIPONTO MIMOSA, MULTIPONTO MIMOSA A5C

Informações Adicionais
