Especificações Técnicas

STANDARDS CONFORMANCE: IEEE 802.3I, 802.3U, 802.3AB, 802.3AF, 802.11D, 802.1X IEEE 802.11A, 802.11B, 802.11G, 802.11N WMM, WPA2/WPA WI-FI CERTIFIED MEDIA INTERFACES: RJ-45 10BASE-T 10/100/1000 INTERFACE WITH 802.3AF POE; RJ-45 CONSOLE PORT; IEEE 802.11A, 802.11B, 802.11G, 802.11N DATA RATES SUPPORTED: 802.11N MCS 0 TO 15 FOR HT20MHZ, 6.5-144 MBPS MCS 0 TO 15 FOR HT40MHZ, 13.5-300 MBPS 802.11A 54, 48, 36, 24, 18, 12, 9 AND 6 MBPS 802.11G 54, 48, 36, 24, 18, 12, 9 AND 6 MBPS 802.11B 11, 5.5, 2 AND 1 MBPS FREQUENCY BAND: IEEE 802.11N: 2.4-2.484 GHZ AND 5.15-5.85 GHZ IEEE 802.11A: 5.15-5.85 GHZ IEEE 802.11B/G: 2.4-2.484 GHZ MODULATION TECHNIQUE: 802.11B: DSSS (DIRECT SEQUENCE SPREAD SPECTRUM) 802.11A/G/N: OFDM (ORTHOGONAL FREQUENCY DIVISION MULTIPLEXING) AND DSSS MEDIA ACCESS PROTOCOL - CSMA/CA WITH ACK OPERATING CHANNELS: CHANNEL AVAILABILITY DEPENDS ON LOCAL COUNTRY REGULATIONS. WIRELESS LAN SYSTEM ADMINISTRATOR MUST CHOOSE CORRECT COUNTRY OF OPERATION. CHANNELS ARE THEN AUTOMATICALLY CONFIGURED TO COMPLY WITH SPECIFIED COUNTRYS REGULATIONS. SECURITY: WPA2- ENTERPRISE, WPA2- PERSONAL, WPA - PERSONAL, WPA- ENTERPRISE, AES/TKIP; WEP 64/128-BIT ENCRYPTION IEEE 802.1X EAP TYPES: EAP-TLS, EAP-TTLS, PEAP MANAGEMENT: MANAGED VIA ACCESS CONTROLLER OR CONSOLE PORT OPERATING VOLTAGE: POE, 48V DC POWER CONSUMPTION: MAX 10W POE LED INDICATORS: POWER, LAN, 2.4 GHZ RADIO, 5 GHZ RADIO ANTENNAS: 3 INTERNAL RADIOS; 3T X 3R DIMENSIONS: DIAMETER: 19.0 CM (7.5 IN.) HEIGHT: 6.0 CM (2.4 IN.) WEIGHT: 0.5 KG (1.1 LB 3CRWE9152A75 ACCESS POINT 3COM 1 PORTA 10/100/1000 TAGS DE 3CRWE9152A75: 3CRWE9152A75, 3COM, ACESS POINT
