Especificações Técnicas

HARDWARE SPECIFICATIONS VERSION 3 COPPER PORTS 8 10/100/1000BASET RJ45 AUTOMDI/MDIX PORTS SFP/MINIGBIC SLOTS 2 1000BASESX/LX/BX SFP INTERFACES (PORT9 AND PORT10) COMPATIBLE WITH 100BASEFX SFP CONSOLE 1 X RJ45TORS232 SERIAL PORT (115200, 8, N, 1) SWITCH ARCHITECTURE STOREANDFORWARD SWITCH FABRIC 20GBPS/NONBLOCKING THROUGHPUT (PACKET PER SECOND) 14.8MPPS@ 64BYTES PACKET ADDRESS TABLE 8K ENTRIES, AUTOMATIC SOURCE ADDRESS LEARNING AND AGING SHARED DATA BUFFER 4MBITS FLOW CONTROL IEEE 802.3X PAUSE FRAME FOR FULLDUPLEX BACK PRESSURE FOR HALFDUPLEX JUMBO FRAME 9KBYTES RESET BUTTON > 5 SEC: FACTORY DEFAULT ESD PROTECTION 6KV DC EFT PROTECTION 6KV DC ENCLOSURE IP30 ALUMINUM CASE INSTALLATION DINRAIL KIT AND WALLMOUNT KIT CONNECTOR REMOVABLE 6PIN TERMINAL BLOCK FOR POWER INPUT PIN 1/2 FOR POWER 1, PIN 3/4 FOR FAULT ALARM, PIN 5/6 FOR POWER 2 REMOVABLE 6PIN TERMINAL BLOCK FOR DI/DO INTERFACE PIN 1/2 FOR DI 1 E 2, PIN 3/4 FOR DO 1 IGS-10020HPT PLANET SWITCH INDUSTRIAL 8 PORTAS IP30 SNMP TAGS DE IGS-10020HPT: IGS-10020HPT, IGS10020HPT, IGS 10020HPT, 8-PORT 10/100/1000T 802.3AF POE + 2-PORT 100/1000X SFP MANAGED SWITCH, PLANET TECHNOLOGY, IGS-10020PT
