Especificações Técnicas

HARDWARE SPECIFICATIONS COPPER PORTS 4 10/100/1000BASET RJ45 AUTO-MDI/MDI-X PORTS POE INJECTOR PORTS FOUR PORTS WITH 802.3AT POE INJECTOR (PORT-1 TO PORT-4) SFP SLOTS (AUTO DETECTION) TWO 1000BASE-SX/LX/BX SFP INTERFACE (PORT 5 TO PORT 6) COMPATIBLE WITH 100BASE-FX SFP DIP SWITCH SWITCH (DEFAULT)/FIBER REDUNDANT MODE CONNECTOR REMOVABLE 6-PIN TERMINAL BLOCK PIN 1/2 FOR POWER 1; PIN 3/4 FOR FAULT ALARM; PIN 5/6 FOR POWER 2 ALARM PROVIDES ONE RELAY OUTPUT FOR POWER FAILURE ALARM RELAY CURRENT CARRY ABILITY: 1A @ 24V DC POWER REQUIREMENTS 12~56V DC, 7A (MAX.) REDUNDANT POWER WITH REVERSE POLARITY PROTECTION POWER CONSUMPTION MAX. 7.02 WATTS/24BTU (ETHERNET FULL LOADING) MAX. 130.6 WATTS/445BTU (ETHERNET POE FULL LOADING) DIMENSIONS (W X D X H) 32 X 87 X 135 MM WEIGHT 657G ENCLOSURE IP40 METAL CASE INSTALLATION DIN-RAIL KIT AND WALL-MOUNT KIT ESD PROTECTION 6KV SWITCH SPECIFICATIONS SWITCH ARCHITECTURE STORE-AND-FORWARD SWITCH FABRIC 12GBPS THROUGHPUT (PACKET PER SECOND) 8.93MPPS@64BYTES ADDRESS TABLE 4K ENTRIES BUFFER MEMORY 1M BITS ON-CHIP BUFFER MEMORY JUMBO FRAME 9KBYTES FLOW CONTROL BACK PRESSURE FOR HALF DUPLEX IEEE 802.3X PAUSE FRAME FOR FULL DUPLEX POWER OVER ETHERNET POE STANDARD IEEE 802.3AT POWER OVER ETHERNET PLUS/PSE POE POWER SUPPLY TYPE END-SPAN POWER PIN ASSIGNMENT 1/2( ), 3/6(-) POE POWER OUTPUT IEEE 802.3AF STANDARD PER PORT 48V~51V DC (DEPENDING ON THE POWER SUPPLY), MAX. 15.4 WATTS IEEE 802.3AT STANDARD PER PORT 51V~56V DC (DEPENDING ON THE POWER SUPPLY), MAX. 36 WATTS POE POWER BUDGET (MAX.) 60W@12V DC INPUT 90W@24V DC INPUT 120W@48V-56V DC INPUT MAX. NUMBER OF CLASS 4 PDS 4 STANDARDS CONFORMANCE REGULATORY COMPLIANCE FCC PART 15 CLASS A, CE STABILITY TESTING IEC 60068-2-32 (FREE FALL) IEC 60068-2-27 (SHOCK) IEC 60068-2-6 (VIBRATION) STANDARDS COMPLIANCE IEEE 802.3 ETHERNET IEEE 802.3U FAST ETHERNET IEEE 802.3AB GIGABIT ETHERNET IEEE 802.3AZ GIGABIT SX/LX IEEE 802.3X FULL-DUPLEX FLOW CONTROL IEEE 802.3AT POWER OVER ETHERNET PLUS PSE IEEE 802.3AF POWER OVER ETHERNET PLUS IEEE 802.1P CLASS OF SERVICE ENVIRONMENT TEMPERATURE OPERATING: -40~75 DEGREES C STORAGE: -40~75 DEGREES C HUMIDITY OPERATING: 5~90% (NON-CONDENSING) STORAGE: 5~90% (NON-CONDENSING) ORDERING INFORMATION IGS-624HPT INDUSTRIAL 4-PORT 10/100/1000T 802.3AT POE 2-PORT 100/1000X SFP ETHERNET SWITCH IGS-624HP PLANET SWITCH INDUSTRIAL 4 PORTAS POE GIGABIT TAGS DE IGS-624HP: IGS-624HP, IGS 624HP, IGS624HP,, SWTICH PLANET IGS-624HP, PLANET IGS-624HP, SWITCH PLANET IGS-624HP, SWITCH PLANET INDUSTRIAL, SWITCH INDUSTRIAL, SWITCH PLANET IGS-624HP, PLANET TECHNOLOGY
