Especificações Técnicas

SWITCH SPECIFICATIONS SFP SLOTS 1 1000BASESX/LX/BX SFP INTERFACE COMPATIBLE WITH 100BASEFX SFP CONNECTOR REMOVABLE 4PIN TERMINAL BLOCK PIN 1/2 FOR POWER 1; PIN 3/4 FOR POWER 2 LED 2 X LED FOR SYSTEM AND POWER:  GREEN: DC POWER 1  GREEN: DC POWER 2 2 X LED FOR EACH COPPER PORT  GREEN: 1000MBPS LNK/ACT  ORANGE:10/100MBPS LNK/ACT 1 X LED FOR SFP FIBER SLOT  GREEN: LNK/ACT ESD PROTECTION 6KV POWER REQUIREMENTS 9~48V DC, REDUNDANT POWER WITH REVERSE POLARITY PROTECTION, 24V AC POWER SUPPORT POWER CONSUMPTION / DISSIPATION 4.3 WATTS/14.67BTU INSTALLATION DINRAIL KIT AND WALLMOUNT EAR ENCLOSURE IP30 METAL CASE DIMENSIONS (W X D X H) 30 X 70 X 104 MM WEIGHT 252G SWITCH PROCESSING SCHEME STOREANDFORWARD ADDRESS TABLE 4K ENTRIES BUFFER MEMORY 1M BITS ONCHIP BUFFER MEMORY FLOW CONTROL BACK PRESSURE FOR HALF DUPLEX IEEE 802.3X PAUSE FRAME FOR FULL DUPLEX SWITCH FABRIC 10GBPS STANDARDS CONFORMANCE THROUGHPUT (PACKET PER SECOND) 7.4MPPS@64BYTES JUMBO FRAME 9K NETWORK CABLES 10/100/1000BASET CAT. 3, 4, 5, 5E, 6 UTP CABLE (MAX. 100 METERS) EIA/TIA568 100OHM STP (MAX. 100 METERS) STANDARDS COMPLIANCE IEEE 802.3 ETHERNET IEEE 802.3U FAST ETHERNET IEEE 802.3AB GIGABIT ETHERNET IEEE 802.3AZ GIGABIT SX/LX IEEE 802.3X FULLDUPLEX FLOW CONTROL IEEE 802.3AZ ENERGY EFFICIENT ETHERNET IEEE 802.1P CLASS OF SERVICE REGULATORY COMPLIANCE FCC PART 15 CLASS A, CE STABILITY TESTING IEC 60068232 (FREE FALL) IEC 60068227 (SHOCK) IEC 6006826 (VIBRATION) TEMPERATURE OPERATING: 40~75 DEGREES C STORAGE: 40~75 DEGREES C ENVIRONMENT HUMIDITY OPERATING: 5~90%, STORAGE: 5~90% (NONCONDENSING) COPPER PORTS 4PORT 10/100/1000BASET RJ45 TP AUTOMDI/MDIX, AUTO NEGOTIATION ORDERING INFORMATION IGS620TF INDUSTRIAL 4PORT 10/100/1000T 2PORT 100/1000X SFP ETHERNET SWITCH IGS-510TF PLANET SWITCH INDUSTRIAL 4 PORTAS GIGABIT TAGS DE IGS-510TF: IGS-510TF, IGS510TF, IGS 510TF, IGS-620TF, SWTICH PLANET IGS-620TF, PLANET IGS-620TF, SWITCH PLANET IGS-620TF, SWITCH PLANET INDUSTRIAL, SWITCH INDUSTRIAL, SWITCH PLANET IGS 620TF, IGS620TF, PLANET TECHNOLOGY, IGS-620TF
