Especificações Técnicas

HARDWARE SPECIFICATIONS COPPER PORTS 4 X 10/100/1000BASE-T RJ-45 TP AUTO-MDI/MDI-X, AUTO-NEGOTIATION SFP / MINI-GBIC SLOTS 2 1000BASE-SX/LX/BX SFP INTERFACES (PORT-5 AND PORT-6) COMPATIBLE WITH 100BASE-FX SFP DIP SWITCH DIP-1: SFP PORT 5 1000BASE-X (DEFAULT) / 100BASE-FX DIP-2: SFP PORT 6 1000BASE-X (DEFAULT)/ 100BASE-FX DIP-3: SWITCH MODE / FIBER REDUNDANT MODE CONNECTOR REMOVABLE 6-PIN TERMINAL BLOCK PIN 1/2 FOR POWER 1; PIN 3/4 FOR FAULT ALARM; PIN 5/6 FOR POWER 2 ALARM PROVIDES ONE RELAY OUTPUT FOR POWER FAILURE  ALARM RELAY CURRENT CARRY ABILITY: 1A @ DC 24V LED 3 X LED FOR SYSTEM AND POWER:  -GREEN: DC POWER 1 -GREEN: DC POWER 2 -GREEN: POWER FAULT 2 X LED FOR PER COPPER PORT (PORT-1~PORT-4): -GREEN: 1000 LNK/ACT -ORANGE:100 LNK/ACT 1 X LED FOR PER MINI-GBIC INTERFACE (PORT-5 AND PORT-6): -GREEN: LNK/ACT ESD PROTECTION 6KV DC EFT PROTECTION 6KV DC ENCLOSURE IP30 TYPE METAL CASE INSTALLATION DIN RAIL KIT AND WALL MOUNT EAR DIMENSIONS (W X D X H) 135 X 87 X 32MM WEIGHT 503G POWER REQUIREMENTS DC 12~48V OR AC 24V REDUNDANT POWER WITH POLARITY REVERSES PROTECTION POWER CONSUMPTION / DISSIPATION 7.2WATTS / 24BTU CABLE TWISTED-PAIR -10BASE-T: 2-PAIR UTP CAT. 3, 4, 5, UP TO 100 METERS -100BASE-TX: 2-PAIR UTP CAT. 5, 5E UP TO 100 METERS -1000BASE-T: 4-PAIR UTP CAT. 5E, 6 UP TO 100 METERS FIBER-OPTIC CABLE -1000BASE-SX: --50/125-M OR 62.5/125-M MULTI-MODE FIBER OPTIC CABLE, UP TO 550M  -1000BASE-LX: --9/125-M SINGLE-MODE FIBER OPTIC CABLE, UP TO 10/20/30/40/50/70/120  --KILOMETERS (VARY ON SFP MODULE) -100BASE-FX: --50/125-M OR 62.5/125-M MULTI-MODE FIBER OPTIC CABLE, UP TO 2  ---KILOMETERS --9/125-M SINGLE-MODE FIBER OPTIC CABLE, UP TO 20/40/60 KILOMETERS  ---(VARY ON SFP MODULE) SWITCH SPECIFICATION SWITCH PROCESSING SCHEME STORE-AND-FORWARD ADDRESS TABLE 1K ENTRIES FLOW CONTROL BACK PRESSURE FOR HALF DUPLEX IEEE 802.3X PAUSE FRAME FOR FULL DUPLEX SWITCH FABRIC 12GBPS THROUGHPUT (PACKET PER SECOND) 8.93MPPS@64BYTES MAXIMUM TRANSMIT UNIT 9216 BYTES SPEED SX/LX: 2000MBPS (FULL-DUPLEX) FX: 200MBPS (FULL-DUPLEX) TP: 10/20MBPS, 100/200MBPS, 2000MBPS STANDARDS CONFORMANCE STANDARDS COMPLIANCE IEEE 802.3 ETHERNET / 10BASE-T IEEE 802.3U FAST ETHERNET / 100BASE-TX IEEE 802.3AB GIGABIT ETHERNET / 1000BASE-T IEEE 802.3Z GIGABIT ETHERNET / 1000BASE-SX/LX IEEE 802.3X FULL-DUPLEX FLOW CONTROL REGULATION COMPLIANCE FCC PART 15 CLASS A, CE STABILITY TESTING IEC60068-2-32(FREE FALL) IEC60068-2-27(SHOCK) IEC60068-2-6(VIBRATION) ENVIRONMENT TEMPERATURE OPERATING: -40~75 DEGREE C STORAGE: -40~75 DEGREES C HUMIDITY OPERATING: 5~95% (NON-CONDENSING) STORAGE: 5~95% (NON-CONDENSING) ORDERING INFORMATION IGS-620TF INDUSTRIAL 4-PORT 10/100/1000T 2-PORT 100/1000X SFP ETHERNET SWITCH IGS-620TF PLANET SWITCH INDUSTRIAL 4 PORTAS GIGABIT TAGS DE IGS-620TF: IGS-620TF, SWTICH PLANET IGS-620TF, PLANET IGS-620TF, SWITCH PLANET IGS-620TF, SWITCH PLANET INDUSTRIAL, SWITCH INDUSTRIAL, SWITCH PLANET IGS 620TF, IGS620TF, PLANET TECHNOLOGY, =IGS-620TF, =IGS-620TF

Informações Adicionais
