Especificações Técnicas

HARDWARE SPECIFICATIONS THERMAL FAN FANLESS COPPER PORT 10 10/100BASE-TX MDI/MDIX PORTS POE INJECTOR PORT 8-PORT WITH 802.3AT/AF POE INJECTOR WITH PORT-1 TO PORT-8 SWITCH ARCHITECTURE STORE-AND-FORWARD SWITCH FABRIC 2GBPS/NON-BLOCKING SWITCH THROUGHPUT@64 BYTES 1.48MPPS@64 BYTES MAC ADDRESS TABLE 8K ENTRIES, AUTOMATIC SOURCE ADDRESS LEARNING AND AGING MAXIMUM FRAME SIZE 1522 BYTES FLOW CONTROL IEEE 802.3X PAUSE FRAME FOR FULL-DUPLEX BACK PRESSURE FOR HALF-DUPLEX LED SYSTEM: POWER (GREEN) 10/100BASE-TX RJ45 INTERFACES: 10/100MBPS LNK/ACT (GREEN) POE INTERFACES: POE-IN-USE (ORANGE) DIP SWITCH SELECTABLE OPERATION MODE STANDARD VLAN EXTEND DIMENSIONS (W X D X H) 220 X 150 X 43 MM (1U HEIGHT) ENCLOSURE METAL WEIGHT 1230 G POWER REQUIREMENTS AC 100~240V, 50/60HZ, 2.5A MAX. POWER CONSUMPTION/ DISSIPATION SYSTEM ON: MAX. 2.4 WATTS/8.1 BTU ETHERNET FULL LOADING: MAX. 5 WATTS/10.2 BTU POE FULL LOADING: MAX. 129 WATTS/440.1 BTU ESD PROTECTION CONTACT DISCHARGE OF 4KV DC AIR DISCHARGE OF 6KV DC POWER OVER ETHERNET POE STANDARD IEEE 802.3AF POWER OVER ETHERNET/PSE IEEE 802.3AT POWER OVER ETHERNET PLUS/PSE POE POWER SUPPLY TYPE END-SPAN POE POWER OUTPUT PER PORT 55V DC, 540MA. MAX. 30 WATTS POWER PIN ASSIGNMENT 1/2( ), 3/6(-) POE POWER BUDGET 120 WATTS MAX. NUMBER OF CLASS 2 PDS 8 MAX. NUMBER OF CLASS 3 PDS 8 MAX. NUMBER OF CLASS 4 PDS 4 STANDARDS CONFORMANCE REGULATORY COMPLIANCE FCC PART 15 CLASS A, CE STANDARDS COMPLIANCE IEEE 802.3 10BASE-T IEEE 802.3U 100BASE-TX IEEE 802.3X FLOW CONTROL AND BACK PRESSURE IEEE 802.3AF POWER OVER ETHERNET IEEE 802.3AT POWER OVER ETHERNET PLUS IEEE 802.3AZ ENERGY EFFICIENT ETHERNET (EEE) ENVIRONMENT OPERATING TEMPERATURE: 0 ~ 50 DEGREES C RELATIVE HUMIDITY: 5 ~ 95% (NON-CONDENSING) STORAGE TEMPERATURE: -10 ~ 70 DEGREES C RELATIVE HUMIDITY: 5 ~ 95% (NON-CONDENSING) ORDERING INFORMATION FSD-1008HP 8-PORT 10/100TX 802.3AT POE 2-PORT 10/100TX DESKTOP SWITCH (120 WATTS) FSD-1008HP PLANET SWITCH 8 PORTAS POE 10/100TX 802.3AT TAGS DE FSD-1008HP: FSD-1008HP, PLANET FSD-1008HP, SWITCH PLANET FSD-1008HP, SWITCH FSD-1008HP, SWITCH PLANET 8 PORTAS, SWITCH 8 PORTAS, SWITCH POE PLANET, SWITCH PLANET POE, SWITCH POE, SWITCH POE 10/100, PLANET TECHNOLOGY
