Especificações Técnicas

HARDWARE SPECIFICATIONS COPPER PORTS 8 10/100/1000BASET RJ45 AUTOMDI/MDIX PORTS, SHARED WITH PORT1~PORT8 SFP/MINIGBIC SLOTS 24 100/1000BASEX DUALSPEED SFP INTERFACES CONSOLE 1 X RS232TORJ45 SERIAL PORT (115200, 8, N, 1) SWITCH ARCHITECTURE STOREANDFORWARD SWITCH FABRIC 48GBPS / NONBLOCKING THROUGHPUT 35.7MPPS@64BYTES ADDRESS TABLE 16K ENTRIES, AUTOMATIC SOURCE ADDRESS LEARNING AND AGEING SHARED DATA BUFFER 16M BITS FLOW CONTROL IEEE 802.3X PAUSE FRAME FOR FULLDUPLEX BACK PRESSURE FOR HALFDUPLEX JUMBO FRAME 10K BYTES RESET BUTTON > 5 SEC: FACTORY DEFAULT DIMENSIONS (W X D X H) 440 X 200 X 44.5 MM, 1U HEIGHT WEIGHT 2745G LED SYSTEM: PWR (GREEN) DC (GREEN) (GS522016S8CR ONLY) FAULT (RED) FAN (RED) 10/100/1000T RJ45 INTERFACES (PORT 1 TO PORT 8): 1000MBPS LNK/ACT (GREEN) 10/100MBPS LNK/ACT (ORANGE) 100/1000MBPS SFP INTERFACES (PORT 1 TO PORT 24): 1000MBPS LNK/ACT (GREEN) 100MBPS LNK/ACT (ORANGE) POWER REQUIREMENTS GS522016S8C: 100~240V AC, 50/60HZ GS522016S8CR: 100~240V AC, 50/60HZ 48V DC @ 0.6A, RANGE: 36 ~ 60V POWER CONSUMPTION 45 WATTS / 153 BTU (MAX.) ESD PROTECTION 6KV DC LAYER 2 FUNCTIONS PORT CONFIGURATION PORT DISABLE / ENABLE AUTONEGOTIATION 10/100/1000MBPS FULL AND HALF DUPLEX MODE SELECTION FLOW CONTROL DISABLE / ENABLE PORT STATUS DISPLAY EACH PORTS SPEED DUPLEX MODE, LINK STATUS, FLOW CONTROL STATUS, AUTONEGOTIATION STATUS, TRUNK STATUS PORT MIRRORING TX / RX / BOTH MANYTO1 MONITOR VLAN 802.1Q TAGGED BASED VLAN QINQ TUNNELING PRIVATE VLAN EDGE (PVE) MACBASED VLAN PROTOCOLBASED VLAN VOICE VLAN IP SUBNETBASED VLAN MVR (MULTICAST VLAN REGISTRATION) UP TO 255 VLAN GROUPS, OUT OF 4094 VLAN IDS LINK AGGREGATION IEEE 802.3AD LACP / STATIC TRUNK 12 GROUPS OF 8PORT TRUNK SUPPORTED SPANNING TREE PROTOCOL STP, IEEE 802.1D SPANNING TREE PROTOCOL RSTP, IEEE 802.1W RAPID SPANNING TREE PROTOCOL MSTP, IEEE 802.1S MULTIPLE SPANNING TREE PROTOCOL QOS TRAFFIC CLASSIFICATION BASED, STRICT PRIORITY AND WRR 8LEVEL PRIORITY FOR SWITCHING PORT NUMBER  802.1P PRIORITY 802.1Q VLAN TAG DSCP/TOS FIELD IN IP PACKET IGMP SNOOPING IGMP (V1/V2/V3) SNOOPING, UP TO 255 MULTICAST GROUPS IGMP QUERIER MODE SUPPORT MLD SNOOPING MLD (V1/V2) SNOOPING, UP TO 255 MULTICAST GROUPS MLD QUERIER MODE SUPPORT ACCESS CONTROL LIST IPBASED ACL / MACBASED ACL UP TO 256 ENTRIES BANDWIDTH CONTROL PER PORT BANDWIDTH CONTROL INGRESS: 100KBPS~1000MBPS EGRESS: 100KBPS~1000MBPS LAYER 3 FUNCTIONS IP INTERFACES MAX. 128 VLAN INTERFACES ROUTING TABLE MAX. 32 ROUTING ENTRIES ROUTING PROTOCOLS IPV4 HARDWARE STATIC ROUTING IPV6 HARDWARE STATIC ROUTING MANAGEMENT BASIC MANAGEMENT INTERFACES CONSOLE / TELNET / WEB BROWSER / SNMP V1, V2C SECURE MANAGEMENT INTERFACES SSH, SSL, SNMP V3 SNMP MIBS RFC 1213 MIBII RFC 1493 BRIDGE MIB RFC 1643 ETHERNET MIB RFC 2863 INTERFACE MIB RFC 2665 ETHERLIKE MIB RFC 2819 RMON MIB (GROUP 1, 2, 3 AND 9) RFC 2737 ENTITY MIB RFC 2618 RADIUS CLIENT MIB RFC 2863 IFMIB RFC 2933 IGMPSTDMIB RFC 3411 SNMPFRAMEWORKSMIB RFC 4292 IP FORWARD MIB RFC 4293 IP MIB RFC 4836 MAUMIB IEEE 802.1X PAE LLDP STANDARDS CONFORMANCE REGULATION COMPLIANCE FCC PART 15 CLASS A, CE STANDARDS COMPLIANCE IEEE 802.3 10BASET IEEE 802.3U 100BASETX/100BASEFX IEEE 802.3Z GIGABIT SX/LX IEEE 802.3AB GIGABIT 1000BASET IEEE 802.3X FLOW CONTROL AND BACK PRESSURE IEEE 802.3AD PORT TRUNK WITH LACP IEEE 802.1D SPANNING TREE PROTOCOL IEEE 802.1W RAPID SPANNING TREE PROTOCOL IEEE 802.1S MULTIPLE SPANNING TREE PROTOCOL IEEE 802.1P CLASS OF SERVICE IEEE 802.1Q VLAN TAGGING IEEE 802.1X PORT AUTHENTICATION NETWORK CONTROL IEEE 802.1AB LLDP RFC 768 UDP RFC 793 TFTP RFC 791 IP RFC 792 ICMP RFC 2068 HTTP RFC 1112 IGMP VERSION 1 RFC 2236 IGMP VERSION 2 RFC 3376 IGMP VERSION 3 RFC 2710 MLD VERSION 1 FRC 3810 MLD VERSION 2 ENVIRONMENT OPERATING TEMPERATURE: 0 ~ 50 DEGREES C RELATIVE HUMIDITY: 5 ~ 95% (NONCONDENSING) STORAGE TEMPERATURE: 10 ~ 70 DEGREES C RELATIVE HUMIDITY: 5 ~ 95% (NONCONDENSING) ORDERING INFORMATION GS522016S8C L2 24PORT 100/1000X SFP 8PORT SHARED TP MANAGED SWITCH GS522016S8CR L2 24PORT 100/1000X SFP 8PORT SHARED TP MANAGED SWITCH REDUNDANT AC/DC POWER GS-5220-16S8C PLANET SWITCH 24 PORTAS SFP GIGABIT + 8 RJ45 MAIORES DETALHES DE GS-5220-16S8C NO SITE DO FABRICANTE: HTTPS://WWW.PLANET.COM.TW/EN/PRODUCT/GS-5220-16S8C-GS-5220-16S8CR TAGS DE GS-5220-16S8C: GS-5220-16S8C, GS 5220 16S8C, GS522016S8C, L2+ 24-PORT 100/1000X SFP + 8-PORT SHARED TP MANAGED SWITCH, SWITCH PLANET 24 PORTAS SFP, SWITCH PLANET 24P, SWITCH 24 PORTAS PLANET, GS-5220-16S8C SW 24P10/1000SFP+8P10/1000, PLANET TECHNOLOGY

Informações Adicionais
