Especificações Técnicas

HARDWARE SPECIFICATIONS HARDWARE VERSION 2 COPPER PORTS 24 X 10/100/1000BASE-T RJ45 AUTO-MDI/MDI-X PORTS POE INJECTOR PORT 24 802.3AF/802.3AT POE INJECTOR PORTS SFP/MINI-GBIC SLOTS 2 100/1000BASE-X SFP INTERFACES, SUPPORTING 100/1000MBPS DUAL MODE CONSOLE 1 X RS-232-TO-RJ45 SERIAL PORT (115200, 8, N, 1) SWITCH ARCHITECTURE STORE-AND-FORWARD SWITCH FABRIC 52GBPS/NON-BLOCKING SWITCH THROUGHPUT@64 BYTES 38.6MPPS @64 BYTES MAC ADDRESS TABLE 8K ENTRIES SHARED DATA BUFFER 4.1 MEGABITS FLOW CONTROL IEEE 802.3X PAUSE FRAME FOR FULL-DUPLEX BACK PRESSURE FOR HALF-DUPLEX JUMBO FRAME 9216 BYTES RESET BUTTON > 5 SEC: FACTORY DEFAULT LED SYSTEM: POWER (GREEN) 10/100/1000T RJ45 INTERFACES (PORT 1 TO PORT 24): 1000 LNK/ACT (GREEN), 10/100 LNK/ACT (ORANGE), POE (ORANGE) 100/1000MBPS SFP INTERFACES (PORT 25 TO PORT 26): 1000 LNK/ACT (GREEN), 100 LNK/ACT (ORANGE) THERMAL FAN 2 POWER REQUIREMENTS 100~240V AC, 50/60HZ, 4A (MAX.) POWER CONSUMPTION/DISSIPATION MAX. 330 WATTS/1122 BTU DIMENSIONS (W X D X H) 445 X 207 X 45 MM (1U HEIGHT) WEIGHT 2.8KG ENCLOSURE METAL POWER OVER ETHERNET POE STANDARD IEEE 802.3AF POWER OVER ETHERNET/PSE IEEE 802.3AT POWER OVER ETHERNET PLUS/PSE POE POWER OUTPUT PER PORT 52V DC, 300MA. MAX. 15.4 WATTS (IEEE 802.3AF) PER PORT 52V DC, 600MA. MAX. 30 WATTS (IEEE 802.3AT) POE POWER BUDGET 300 WATTS NUMBER OF PDS, 7 WATTS 24 NUMBER OF PDS, 15.4 WATTS 19 NUMBER OF PDS, 30 WATTS 9 LAYER 2 FUNCTIONS PORT MIRRORING TX/RX/BOTH MANY-TO-1 MONITOR VLAN 802.1Q TAGGED-BASED VLAN UP TO 256 VLAN GROUPS, OUT OF 4094 VLAN IDS 802.1AD Q-IN-Q TUNNELING VOICE VLAN PROTOCOL VLAN PRIVATE VLAN (PROTECTED PORT) GVRP MANAGEMENT VLAN LINK AGGREGATION IEEE 802.3AD LACP SUPPORTS 1 GROUP OF 2-PORT TRUNK AND STATIC TRUNK SUPPORTS 1 GROUP OF 2-PORT TRUNK SPANNING TREE PROTOCOL IEEE 802.1D SPANNING TREE PROTOCOL (STP) IEEE 802.1W RAPID SPANNING TREE PROTOCOL (RSTP) IEEE 802.1S MULTIPLE SPANNING TREE PROTOCOL (MSTP) IGMP SNOOPING IGMP (V2/V3) SNOOPING IGMP QUERIER UP TO 256 MULTICAST GROUPS MLD SNOOPING IPV6 MLD (V1/V2) SNOOPING, UP TO 256 MULTICAST GROUPS ACCESS CONTROL LIST IPV4/IPV6 IP-BASED ACL/MAC-BASED ACL PV4/IPV6 IP-BASED ACE/MAC-BASED ACE QOS 8 MAPPING IDS TO 8 LEVEL PRIORITY QUEUES PORT NUMBER 802.1P PRIORITY DSCP/IP PRECEDENCE OF IPV4/IPV6 PACKETS TRAFFIC CLASSIFICATION BASED, STRICT PRIORITY AND WRR INGRESS/EGRESS RATE LIMIT PER PORT BANDWIDTH CONTROL SECURITY IEEE 802.1X PORT-BASED AUTHENTICATION BUILT-IN RADIUS CLIENT TO COOPERATE WITH RADIUS SERVER RADIUS/TACACS AUTHENTICATION IP-MAC PORT BINDING MAC FILTERING STATIC MAC ADDRESS DHCP SNOOPING AND DHCP OPTION82 STP BPDU GUARD, BPDU FILTERING AND BPDU FORWARDING DOS ATTACK PREVENTION ARP INSPECTION IP SOURCE GUARD STORM CONTROL SUPPORT BROADCAST/UNKNOWN UNICAST/UNKNOWN MULTICAST MANAGEMENT FUNCTIONS BASIC MANAGEMENT INTERFACES RJ45 CONSOLE; WEB BROWSER; TELNET; SNMP V1, V2C, V3 FIRMWARE UPGRADE BY HTTP/TFTP PROTOCOL THROUGH ETHERNET NETWORK CONFIGURATION UPLOAD/DOWNLOAD THROUGH HTTP/TFTP REMOTE/LOCAL SYSLOG SYSTEM LOG LLDP PROTOCOL SNTP PLANET SMART DISCOVERY UTILITY SECURE MANAGEMENT INTERFACES HTTPS, SNMP V3 SNMP MIBS RFC 3635 ETHERNET-LIKE MIB RFC 2863 INTERFACE GROUP MIB RFC 2819 RMON (1, 2, 3, 9) RFC 1493 BRIDGE MIB STANDARDS CONFORMANCE REGULATORY COMPLIANCE FCC PART 15 CLASS A, CE STANDARDS COMPLIANCE IEEE 802.3 10BASE-T IEEE 802.3U 100BASE-TX/100BASE-FX IEEE 802.3Z GIGABIT SX/LX IEEE 802.3AB GIGABIT 1000T IEEE 802.3X FLOW CONTROL AND BACK PRESSURE IEEE 802.3AD PORT TRUNK WITH LACP IEEE 802.1D SPANNING TREE PROTOCOL IEEE 802.1W RAPID SPANNING TREE PROTOCOL IEEE 802.1S MULTIPLE SPANNING TREE PROTOCOL IEEE 802.1P CLASS OF SERVICE IEEE 802.1Q VLAN TAGGING IEEE 802.1X PORT AUTHENTICATION NETWORK CONTROL IEEE 802.1AB LLDP IEEE 802.3AF POWER OVER ETHERNET IEEE 802.3AT POWER OVER ETHERNET PLUS RFC 768 UDP RFC 793 TFTP RFC 791 IP RFC 792 ICMP RFC 2068 HTTP RFC 1112 IGMP VERSION 1 RFC 2236 IGMP VERSION 2 RFC 3376 IGMP VERSION 3 RFC 2710 MLD VERSION 1 RFC 3810 MLD VERSION 2 ENVIRONMENT OPERATING TEMPERATURE: 0 ~ 50 DEGREES C RELATIVE HUMIDITY: 5 ~ 95% (NON-CONDENSING) STORAGE TEMPERATURE: -10 ~ 70 DEGREES C RELATIVE HUMIDITY: 5 ~ 95% (NON-CONDENSING) GS-4210-24P2S PLANET SWITCH 24 PORTAS GIGABIT TAGS DE GS-4210-24P2S: GS-4210-24P2S, GS 4210 24P2S, GS421024P2S, SWITCH PLANATE 24-PORT, 24 PORTAS GIGABIT, SWITCH 10/100/1000 PLANET, PLANET TECHNOLOGY, SWITCH POE
