Especificações Técnicas

HARDWARE SPECIFICATIONS COPPER PORTS    28 X 10/100/1000BASE-T RJ45 AUTO-MDI/MDI-X PORT SFP/MINI-GBIC SLOTS    4 X 100/1000BASE-X SFP INTERFACE SHARED WITH PORT-25 TO PORT-28 SUPPORTS 100/1000MBPS DUAL MODE AND DDM POE INJECTOR PORT    24 PORTS WITH 802.3AT / AF POE INJECTOR WITH PORT-1 TO PORT-24 CONSOLE    1 X RS232-TO-RJ45 SERIAL PORT (115200, 8, N, 1) SWITCH ARCHITECTURE    STORE-AND-FORWARD SWITCH FABRIC    56GBPS / NON-BLOCKING SWITCH THROUGHPUT@64BYTES    41.67MPPS ADDRESS TABLE    8K ENTRIES SHARED DATA BUFFER    4.1 MEGABITS FLOW CONTROL    IEEE 802.3X PAUSE FRAME FOR FULL-DUPLEX BACK PRESSURE FOR HALF-DUPLEX JUMBO FRAME    10K BYTES RESET BUTTON > 5 SEC: FACTORY DEFAULT LED    PWR, SYS, LNK/ACT, POE-IN-USE, 1000, FAN 1 ALERT, FAN 2 ALERT, POE PWR ALERT POWER REQUIREMENTS    100~240V AC, 50/60HZ, AUTO-SENSING DIMENSIONS (W X D X H)    440 X 300 X 44.5 MM, 1U HEIGHT ESD PROTECTION    CONTACT DISCHARGE 4KV DC AIR DISCHARGE 8KV DC ENCLOSURE    METAL WEIGHT    GS-4210-24P4C: 4214G GS-4210-24PL4C: 4814G POWER CONSUMPTION / DISSIPATION    GS-4210-24P4C: 275 WATTS (MAX.) / 938.3 BTU GS-4210-24PL4C: 544 WATTS (MAX.) / 1856.2 BTU FAN    GS-4210-24P4C: 2 X SMART FAN GS-4210-24PL4C: 3 X SMART FAN POWER OVER ETHERNET POE STANDARD    IEEE 802.3AF / 802.3AT POE PSE POE POWER SUPPLY TYPE    END-SPAN POE POWER OUTPUT    PER PORT 52V DC, 30.8 WATTS (MAX.) POWER PIN ASSIGNMENT    1/2( ), 3/6(-) POE POWER BUDGET    GS-4210-24P4C: -220 WATTS (MAX.) @ 25 DEGREES C -190 WATTS (MAX.) @ 50 DEGREES C GS-4210-24PL4C: -440 WATTS (MAX.) @ 25 DEGREES C -380 WATTS (MAX.) @ 50 DEGREES C POE ABILITY PD @ 9 WATTS    GS-4210-24P4C: 24 UNITS GS-4210-24PL4C: 24 UNITS POE ABILITY PD @ 15.4 WATTS    GS-4210-24P4C: 14 UNITS GS-4210-24PL4C: 24 UNITS POE ABILITY PD @ 30 WATTS    GS-4210-24P4C: 7 UNITS GS-4210-24PL4C: 14 UNITS LAYER 2 FUNCTIONS PORT MIRRORING    TX / RX / BOTH MANY-TO-1 MONITOR VLAN    802.1Q TAGGED-BASED VLAN UP TO 256 VLAN GROUPS, OUT OF 4094 VLAN IDS 802.1AD Q-IN-Q TUNNELING VOICE VLAN PROTOCOL VLAN PRIVATE VLAN (PROTECTED PORT) GVRP LINK AGGREGATION    IEEE 802.3AD LACP AND STATIC TRUNK SUPPORTS 8 GROUPS OF 8-PORT TRUNK SPANNING TREE PROTOCOL    STP, IEEE 802.1D SPANNING TREE PROTOCOL RSTP, IEEE 802.1W RAPID SPANNING TREE PROTOCOL MSTP, IEEE 802.1S MULTIPLE SPANNING TREE PROTOCOL IGMP SNOOPING    IGMP (V2/V3) SNOOPING IGMP QUERIER UP TO 256 MULTICAST GROUPS MLD SNOOPING    MLD (V1/V2) SNOOPING, UP TO 256 MULTICAST GROUPS ACCESS CONTROL LIST    IPV4/IPV6 IP-BASED ACL / MAC-BASED ACL QOS    8 MAPPING ID TO 8 LEVEL PRIORITY QUEUES -PORT NUMBER -802.1P PRIORITY -802.1Q VLAN TAG -DSCP FIELD IN IP PACKET TRAFFIC CLASSIFICATION BASED, STRICT PRIORITY AND WRR SECURITY    IEEE 802.1X PORT-BASED AUTHENTICATION BUILT-IN RADIUS CLIENT TO CO-OPERATE WITH RADIUS SERVER RADIUS / TACACS USER ACCESS AUTHENTICATION IP-MAC PORT BINDING MAC FILTERING STATIC MAC ADDRESS DHCP SNOOPING AND DHCP OPTION82 STP BPDU GUARD, BPDU FILTERING AND BPDU FORWARDING DOS ATTACK PREVENTION ARP INSPECTION IP SOURCE GUARD MANAGEMENT FUNCTIONS BASIC MANAGEMENT INTERFACES    WEB BROWSER / TELNET / SNMP V1, V2C FIRMWARE UPGRADE BY HTTP / TFTP PROTOCOL THROUGH ETHERNET NETWORK REMOTE / LOCAL SYSLOG SYSTEM LOG LLDP PROTOCOL SNTP SECURE MANAGEMENT INTERFACES    SSH, SSL, SNMP V3 SNMP MIBS    RFC 1213 MIB-II RFC 1215 GENERIC TRAPS RFC 1493 BRIDGE MIB RFC 2674 BRIDGE MIB EXTENSIONS RFC 2737 ENTITY MIB (VERSION 2) RFC 2819 RMON (1, 2, 3, 9) RFC 2863 INTERFACE GROUP MIB RFC 3635 ETHERNET-LIKE MIB STANDARDS CONFORMANCE REGULATION COMPLIANCE    FCC PART 15 CLASS A, CE STANDARDS COMPLIANCE    IEEE 802.3 10BASE-T IEEE 802.3U 100BASE-TX/100BASE-FX IEEE 802.3Z GIGABIT SX/LX IEEE 802.3AB GIGABIT 1000T IEEE 802.3X FLOW CONTROL AND BACK PRESSURE IEEE 802.3AD PORT TRUNK WITH LACP IEEE 802.1D SPANNING TREE PROTOCOL IEEE 802.1W RAPID SPANNING TREE PROTOCOL IEEE 802.1S MULTIPLE SPANNING TREE PROTOCOL IEEE 802.1P CLASS OF SERVICE IEEE 802.1Q VLAN TAGGING IEEE 802.1X PORT AUTHENTICATION NETWORK CONTROL IEEE 802.1AB LLDP IEEE 802.3AF POWER OVER ETHERNET IEEE 802.3AT POWER OVER ETHERNET PLUS RFC 768 UDP RFC 793 TFTP RFC 791 IP RFC 792 ICMP RFC 2068 HTTP RFC 1112 IGMP VERSION 1 RFC 2236 IGMP VERSION 2 RFC 3376 IGMP VERSION 3 RFC 2710 MLD VERSION 1 RFC 3810 MLD VERSION 2 ENVIRONMENT OPERATING    TEMPERATURE: 0 ~ 50 DEGREES C RELATIVE HUMIDITY: 5 ~ 95% (NON-CONDENSING) STORAGE    TEMPERATURE: -20 ~ 70 DEGREES C RELATIVE HUMIDITY: 5 ~ 95% (NON-CONDENSING) GS-4210-24PL4C PLANET SWITCH 24 PORTAS GIGABIT POE 802.1Q TAGS DE GS-4210-24PL4C: GS-4210-24PL4C
