Especificações Técnicas

PRODUCT PROTOCOL IEEE 802.3, 10BASET IEEE 802.3U, 100BASETX IEEE 802.3U, 100BASEFX IEEE 802.3X, FLOW CONTROL DIMENSIONS (W X D X H) 97 X 69 X 26 MM WEIGHT 0.2KG POWER INPUT 5V DC, 2A, MAX. POWER SUPPLY AC ADAPTER 100240VAC FREQUENCY: 5060HZ ENCLOSURE COMPACTSIZED METAL HOUSING CASE WITH ANTICORROSION TREATMENT ELECTROSTATIC PAINT CONNECTORS AND CABLES SHIELDED TWISTEDPAIR RJ45, CATEGORY 5 (EIA/TIA 568) FIBEROPTIC FT801 : ST / MULTIMODE / 2KM FT802 : SC / MULTIMODE / 2KM FT803: MTRJ / MULTIMODE / 2KM FT802S15 : SC / SINGLE MODE / 15KM FT802S35 : SC / SINGLE MODE / 35KM FT802S50 : SC / SINGLE MODE / 50KM FT806A20: WDM SC / SINGLE MODE / 20KM FT806B20: WDM SC / SINGLE MODE / 20KM FT806A60: WDM SC / SINGLE MODE / 60KM FT806B60: WDM SC / SINGLE MODE / 60KM MULTIMODE CABLE 50/125, 62.5/125 M SINGLEMODE (SM) CABLE 9/125 M OPTIC WAVELENGTH FT801: 1310NM FT802: 1310NM FT803: 1310NM FT802S15: 1310NM FT802S35: 1310NM FT802S50: 1310NM FT806A20: TX: 1310NM; RX: 1550NM FT806B20: TX: 1550NM; RX: 1310NM FT806A60: TX: 1310NM; RX: 1550NM FT806B60: TX: 1550NM; RX: 1310NM MAX. LAUNCH POWER (DBM) FT801: 14 FT802: 14 FT803: 14 FT802S15:0 FT802S35:8 FT802S50:0 FT806A20:8 FT806B20:8 FT806A60:0 FT806B60:0 MIN. LAUNCH POWER (DBM) FT801: 20 (62.5/125M), 23.5 (50/125M) FT802: 20 (62.5/125M), 23.5 (50/125M) FT803: 20 (62.5/125M), 23.5 (50/125M) FT802S15: 20 FT802S35: 15 FT802S50:5 FT806A20:14 FT806B20:14 FT806A60:5 FT806B60:5 RECEIVE SENSITIVITY (DBM) FT801: 31.8 FT802: 31.8 FT803: 31.8 FT802S15: 32 FT802S35:34 FT802S50: 35 FT806A20:31 FT806B20:31 FT806A60:34 FT806B60:34 MAXIMUM INPUT POWER (DBM) FT801: 14 FT802: 14 FT803: 14 FT802S15:0 FT802S35:0 FT802S50:0 FT806A20:0 FT806B20:0 FT806A60:0 FT806B60:0 SUPPORTED DISTANCES AND FUNCTIONS SHIELDED TWISTEDPAIR 100M (328 FT.) MULTIMODE FIBER OPTIC 412M (1,350 FT.) (HALFDUPLEX) 2KM (1.2 MILES) (FULLDUPLEX) SINGLEMODE (SM) 412M (1,350 FT.) (HALFDUPLEX) 15KM (9 MILES) (FULLDUPLEX) 20KM (12 MILES) (FULLDUPLEX) 35KM (21 MILES) (FULLDUPLEX) 50KM (31 MILES) (FULLDUPLEX) 60KM (37 MILES) (FULLDUPLEX) PORT MODE TP: HALF AND FULL DUPLEX, AUTONEGOTIATION FX: HALF AND FULL DUPLEX VIA DIP SWITCH ENVIRONMENT E EMISSIONS OPERATING ENVIRONMENT TEMPERATURE: 0~50 DEGREES C HUMIDITY: 5~90% NONCONDENSING STORAGE ENVIRONMENT TEMPERATURE: 40~70 DEGREES C HUMIDITY: 5~90% NONCONDENSING EMISSIONS FCC CLASS A, CE CLASS A FT-802S15 PLANET CONVERSOR DE MIDIA 10/100 SC 15KM MAIORES DETALHES DE FT-802S15 NO SITE DO FABRICANTE: HTTP://WWW.PLANET.COM.BR/INDEX.PHP?OPTION=COM_K2&VIEW=ITEM&ID=260:FT-80X-SERIES& TAGS DE FT-802S15: FT-802S15, FT802S15, MIDEA, MEDIA, MEDIA CONVERTER, MC110CS, FT-802-S-15, CONVERSOR DE MIDIA, PLANET, CONVERSOR MIDIA, CONVERSOR DE MIDIA MONOMODO, CONVERSOR 15KM PLANET, PLANET TECHNOLOGY, FT-802-S15
