Especificações Técnicas

THE RB912UAG-2HPND IS A VERY VERSATILE DEVICE. IT IS A SMALL WIRELESS ROUTER WITH AN INTEGRATED 2.4GHZ HIGH POWER WIRELESS CARD AND AN ADDITIONAL MINIPCIE SLOT FOR 802.11 WIRELESS, OR 3G CARD. THE GIGABIT PORT HELPS TO UTILIZE THE FULL POTENTIAL OF 802.11N WIRELESS SPEEDS. THE INTEGRATED WIRELESS CARD IS CAPABLE OF UP TO 1000MW OUTPUT POWER. IT HAS BUILT IN 16KV ESD PROTECTION ON BOTH THE ETHERNET AND THE MMCX PORTS. SPECIFICATIONS: PRODUCT CODE RB912UAG-2HPND CPU NOMINAL FREQUENCY 600 MHZ CPU CORE COUNT 1 SIZE OF RAM 64 MB ARCHITECTURE MIPS-BE 10/100 ETHERNET PORTS 0 10/100/1000 ETHERNET PORTS 1 MINIPCI SLOTS 0 MINIPCI-E SLOTS 1 WIRELESS CHIP MODEL AR9342-BL1A WIRELESS STANDARDS 802.11B/G/N NUMBER OF USB PORTS 1 POWER JACK 1 802.3AF SUPPORT NO POE IN YES POE OUT NO SUPPORTED INPUT VOLTAGE 8 V - 30 V VOLTAGE MONITOR YES CPU TEMPERATURE MONITOR NO PCB TEMPERATURE MONITOR YES DIMENSIONS 105X105MM OPERATING SYSTEM ROUTEROS OPERATING TEMPERATURE RANGE -40°C .. 70°C TESTED LICENSE LEVEL 4 ANTENNA GAIN DBI NO CURRENT MONITOR NO CPU AR9342-BL1A SFP PORTS 0 SFP PORTS 0 USB SLOT TYPE USB TYPE A NUMBER OF CHAINS 2 SERIAL PORT NONE WIRELESS SPECIFICATIONS 2.4 GHZ TX RX 1MBIT/S 30 -100 11MBIT/S 30 -94 6MBIT/S 30 -96 54MBIT/S 27 -78 MCS0 30 -96 MCS7 24 -73 PERFORMANCE TEST RESULTS: RB912UAG-2HPND AR9342 1G 1 PORT TEST MODE CONFIGURATION 1518 BYTE 512 BYTE 64 BYTE KPPS MBPS KPPS MBPS KPPS MBPS BRIDGING NONE (FAST PATH) 81.0 983.7 232.0 950.3 269.6 138.0 BRIDGING 25 BRIDGE FILTER RULES 81.0 983.7 86.0 352.3 87.6 44.9 ROUTING NONE (FAST PATH) 81.0 983.7 210.0 860.2 226.9 116.2 ROUTING 25 SIMPLE QUEUES 81.0 983.7 103.9 425.6 106.6 54.6 ROUTING 25 IP FILTER RULES 56.8 689.8 59.6 244.1 60.5 31.0 RB912UAG-2HPND PLACA ROUTERBOARD MIKROTIK 600 MHZ TAGS DE RB912UAG-2HPND: ROUTER BOARD, RB912UAG-2HPND, RB912UAG2HPND, RB912 UAG 2HPND, RB 912 UAG 2HP ND, MIKROTIK 600 MHZ, AR9342-BL1A, ROUTERBOARD GIGABIT, MIKROTIK PLACA, RB912UAG-2HPND-OUTDOOR, BASEBOX-2

Informações Adicionais
