Especificações Técnicas

ESPECIFICAÇÕES:   CPU: AMD SOCKET FM2+ ATHLON™/ASERIES PROCESSORS  SUPPORTS CPU UP TO 4 CORES SUPPORTS AMD® TURBO CORE 3.0 TECHNOLOGY   CHIPSET: AMD A68H FCH (BOLTON D2H)   MEMORIA: 2 X DIMM, MAX. 32GB, DDR3 2400(O.C.)/2133/1866/1600/1333 MHZ NON-ECC, UN-BUFFERED MEMORY  DUAL CHANNEL MEMORY ARCHITECTUREGRAFICO: INTEGRATED AMD RADEON™ R/HD8000/HD7000 SERIES GRAPHICS IN THE A-SERIES  APU  MULTI-VGA OUTPUT SUPPORT : HDMI/DVI/RGB PORTS  SUPPORTS HDMI WITH MAX. RESOLUTION 4096 X 2160 @ 24 HZ / 1920 X 1200 @ 60 HZ SUPPORTS DVI WITH MAX. RESOLUTION 2560 X 1600 @ 60 HZ SUPPORTS RGB WITH MAX. RESOLUTION 1920 X 1600 @ 60 HZ MAXIMUM SHARED MEMORY OF 2048 MB AMD® DUAL GRAPHICS TECHNOLOGY SUPPORT   SLOTS EXPANSÃO: 1 X PCIE 3.0/2.0 X16 *2 1 X PCIE 2.0 X1  1 X PCI   STORAGE: AMD A68H FCH (BOLTON D2H) CHIPSET :  4 X SATA 6GB/S PORT(S), GRAY,  SUPPORT RAID 0, 1, 10, JBOD   LAN: REALTEK® 8111GR, 1 X GIGABIT LAN CONTROLLER(S)   AUDIO: EALTEK® ALC887-VD 8-CHANNEL HIGH DEFINITION AUDIO CODEC *3 SUPPORTS : JACK-DETECTION, FRONT PANEL JACK-RETASKING AUDIO FEATURE : LED-LIT AUDIO SHIELDING: ENSURES PRECISION ANALOG/DIGITAL SEPARATION AND GREATLY REDUCED MULTI-LATERAL INTERFERENCE, WITH A GORGEOUS ILLUMINATED TRACE PATH DEDICATED AUDIO PCB LAYERS: SEPARATE LAYERS FOR LEFT AND RIGHT CHANNELS TO GUARD THE QUALITY OF THE SENSITIVE AUDIO SIGNALS PREMIUM JAPANESE-MADE AUDIO CAPACITORS: PROVIDE WARM, NATURAL AND IMMERSIVE SOUND WITH EXCEPTIONAL CLARITY AND FIDELITY   CONECTORES: 1 X PS/2 KEYBOARD (PURPLE) 1 X PS/2 MOUSE (GREEN) 1 X DVI 1 X D-SUB 1 X HDMI 1 X LAN (RJ45) PORT(S) 2 X USB 3.0  2 X USB 2.0  3 X AUDIO JACK(S) 90MB0L40-M0EAY0 PLACA MÃE ASUS A68HM PLUS AMD FM2+ MAIORES DETALHES DE 90MB0L40-M0EAY0 NO SITE DO FABRICANTE: HTTPS://WWW.ASUS.COM/BR/MOTHERBOARDS/A68HMPLUS/ TAGS DE 90MB0L40-M0EAY0: 90MB0L40M0EAY0, A68HM-PLUS, A68H, A68HM-PLUS~90MB0L40-M0EAY0, A68HM-PLUS 90MB0L40-M0EAY0, CHIPSET A68H, PLACA MÃE A68H, PLACA MÃE FM2, PLACA MÃE FM2+, PLACA MÃE ASUS FM2+, PLACA MÃE ASUS FM2, PLACA MÃE AMD, PLACA MÃE AMD FM2+, AMD FM2+

Informações Adicionais
