Especificações Técnicas

TYPE HDMI AND ANALOG CAPTURE CARD COMPATIBLE WITH MICROSOFT WINDOWS 7, APPLE MAC OS X, AND LINUX VIDEO SYSTEM NTSC/PAL, HD VIDEO FORMATS 1080I50, 1080I59.94, 1080I60, 1080P23.98, 1080P24, 1080P25, 1080P29.97, 1080P30, 720P50, 720P59.94, 720P60, 625I 50 PAL, AND 525I59.94 NTSC HDMI FORMATS: 525 NTSC, 625 PAL, 720HD, AND 1080HD SWITCHABLE VIDEO SAMPLING HDMI: 4:2:2 AUDIO SAMPLING HDMI: TELEVISION STANDARD SAMPLE RATE OF 48 KHZ AND 24-BIT COLOR PRECISION HDMI: 4:2:2 COLOR SPACE HDMI: YUV 4:2:2 COPY PROTECTION FOR LEGAL REASONS HDMI INPUT IS UNABLE TO CAPTURE FROM COPY PROTECTED HDMI SOURCES. ALWAYS CONFIRM COPYRIGHT OWNERSHIP BEFORE CAPTURE OR DISTRIBUTION OF CONTENT HOST CONNECTION 1X PCI EXPRESS SLOT, COMPATIBLE WITH 1-, 4-, 8-, AND 16-LANE PCIE SLOTS INPUT AND OUTPUT CONNECTORS 1X HDMI INPUT (2-CHANNEL AUDIO) 1X HDMI OUTPUT (2-CHANNEL AUDIO) 1X BREAKOUT CONNECTION WITH RCA COMPOSITE, RCA COMPONENT, RCA STEREO AUDIO (24-BIT), AND S-VIDEO INPUT AND OUTPUT, PLUS STEREO S/PDIF OUTPUT (24-BIT) CONVERSION COLORSPACE CONVERSION: HARDWARE-BASED REAL-TIME HD DOWN CONVERSION: SOFTWARE-BASED DOWN CONVERSION DURING VIDEO PLAYBACK HD UP CONVERSION: REAL-TIME STANDARD DEFINITION TO 1080HD AND 720HD DURING VIDEO CAPTURE HARDWARE REAL-TIME EFFECTS AVID MEDIA COMPOSER 6 INTERNAL EFFECTS IN DNXHD, XDCAM, AND UNCOMPRESSED APPLE FINAL CUT PRO INTERNAL EFFECTS IN DV, DVCPRO HD, PRORES, AND UNCOMPRESSED ON INTEL MAC OS X ADOBE PREMIERE PRO MERCURY PLAYBACK ENGINE EFFECTS IN DV, MJPEG, DVCPRO HD, DSLR, AVCHD, XDCAM, XDCAM HD, AND UNCOMPRESSED INCLUDED SOFTWARE MEDIA EXPRESS, DISK SPEED TEST, BLACKMAGIC SYSTEM PREFERENCES, AND BLACKMAGIC DRIVER FIRMWARE UPGRADE FIRMWARE BUILT INTO SOFTWARE DRIVER. LOADED AT SYSTEM START, OR VIA UPDATER SOFTWARE MINIMUM SYSTEM REQUIREMENTS MAC: MAC OS X 10.6.5, 10.7.X 2008 INTEL MAC PRO (MAC PRO 3,1); 2009 INTEL MAC PRO MAC PRO 4,1); 2010 INTEL MAC PRO (MAC PRO 5,1) 4 GB SYSTEM MEMORY HIGH-SPEED STORAGE WITH PLENTY OF CAPACITY IS REQUIRED TO CAPTURE AND PLAY BACK UNCOMPRESSED DIGITAL VIDEO. COMPRESSED VIDEO FORMATS USE LESS SPACE AND CAN USUALLY BE CAPTURED AND PLAYED BACK WITH ONE HARD DISK WINDOWS: WINDOWS 7 64-BIT APPLE QUICKTIME NEEDS TO BE INSTALLED FOR SOME APPLICATIONS TO WITH A BLACKMAGIC CAPTURE CARD, E.G., ADOBE AFTER EFFECTS, AUTODESK COMBUSTION IN GENERAL, YOU SHOULD CHOOSE A CPU THAT MEETS OR EXCEEDS THE SYSTEM REQUIREMENTS OF THE SOFTWARE APPLICATION YOU ARE PLANNING ON USING THE FOLLOWING WORKSTATIONS ARE CERTIFIED: HEWLETT PACKARD Z400; HEWLETT PACKARD Z600; HEWLETT PACKARD Z800; HEWLETT PACKARD XW9300; HEWLETT PACKARD XW8600 THE FOLLOWING MOTHERBOARDS ARE RECOMMENDED: ASUS P5E; ASUS P5B; ASUS P5Q PRO TURBO; ASUS P6X58D (BIOS LATER THAN 12.04.2010); ASUS P8P67 PRO (REV 3.1); GIGABYTE EP45-DS3; GIGABYTE X48DQ6; GIGABYTE GA-P67A-UD7-B3 (REV. 1.0); INTEL D975XBX; XFX 790I ULTRA LINUX: NOT SPECIFIED BY MANUFACTURER BINTSPRO BLACKMAGIC PLACA DE CAPTURA INTENSITY PRO HDMI TAGS DE BINTSPRO: BINTSPRO, INTENSITYPRO, BLACKMAGIC, PLACA DE CAPTURA BLACKMAGIC, INTENSITY, PLACA DE CAPTURA HDMI, BLACKMAGIC DESIGN
