Especificações Técnicas

OUTROS PART NUMBERS PARA ESTE COMPONENTE: GS110TP-300NAS ESPECIFICAÇÕES   NETWORK PROTOCOL AND STANDARDS COMPATIBILITY   IEEE 802.3I 10BASE-T IEEE 802.3U 100BASE-TX IEEE 802.3AB 1000BASE-T IEEE 802.3Z 1000BASE-X IEEE 802.3X FULL-DUPLEX FLOW CONTROL IEEE 802.3AF (DTE POWER VIA MDI)   POWER SUPPLY POWER CONSUMPTION: 59.3W MAXIMUM   NETWORK PORTS EIGHT (8) 10/100/1000MBPS AUTOSENSING 2 GIGABIT SFP UPLINKS   PHYSICAL SPECIFICATIONS DIMENSIONS: (W X D X H): 236 X 101.6 X 27MM (9.3 X 4 X 1.07IN) WEIGHT: 0.7KG (1.55LB)   PERFORMANCE SPECIFICATIONS FORWARDING MODES: STORE-AND-FORWARD BANDWIDTH: 20GBPS FULL DUPLEX NETWORK LATENCY: LESS THAN 4 -S FOR 64-BYTE FRAMES IN STORE-AND-FORWARD MODE FOR 1000MBPS TO 1000MBPS TRANSMISSION BUFFER MEMORY: 512KB EMBEDDED MEMORY PER UNIT ADDRESS DATABASE SIZE: 4K MEDIA ACCESS CONTROL (MAC) ADDRESSES PER SYSTEM MEAN TIME BETWEEN FAILURES (MTBF): 157,004 HOURS (~18 YEARS) ACOUSTIC NOISE: 0 D   ELECTROMAGNETIC EMISSIONS CE MARK, COMMERCIAL FCC PART 15 CLASS B VCCI CLASS B C-TICK   ENVIRONMENTAL SPECIFICATIONS OPERATING TEMPERATURE: 32° TO 122°F (0° TO 50°C) STORAGE TEMPERATURE: -4° TO 158°F (-20° TO 70°C) OPERATING HUMIDITY: 90% MAXIMUM RELATIVE HUMIDITY, NON-CONDENSING STORAGE HUMIDITY: 95% MAXIMUM RELATIVE HUMIDITY, NON-CONDENSING OPERATING ALTITUDE: 10,000FT (3,000M) MAXIMUM STORAGE ALTITUDE: 10,000FT (3,000M) MAXIMUM   STATUS LEDS PER RJ45 PORT: LINK/ACTIVITY, SPEED, POE STATUS PER SFP PORT: LINK/SPEED PER DEVICE: POWER, POE MAX   POWER ADAPTER 48V, 1.25A EXTERNAL POWER ADAPTER, LOCALIZED TO COUNTRY OF SALE   ELECTROMAGNETIC IMMUNITY EN 55024   SAFETY CE MARK, COMMERCIAL CUL IEC 950/EN 60950 CB   ADMINISTRATIVE SWITCH MANAGEMENT IEEE 802.1Q STATIC VLAN (64 GROUPS, STATIC) PROTECTED PORTS IEEE 802.1P CLASS OF SERVICE (COS) PORT-BASED QOS DSCP-BASED QOS DIFFSERV IEEE 802.3AD LINK AGGREGATION (MANUAL OR LACP) IEEE 802.1W RAPID SPANNING TREE PROTOCOL (RSTP) IEEE 802.1S MULTIPLE SPANNING TREES PROTOCOL (MSTP) IEEE 802.1AB LINK LAYER DISCOVERY PROTOCOL (LLDP) LLDP-MED SNMP V1, V2C, V3 RFC 1213 MIB II RFC 1643 ETHERNET INTERFACE MIB RFC 1493 BRIDGE MIB RMON GROUP 1, 2, 3, 9 AUTO VOICE VLAN DHCP FILTERING AUTO DENIAL-OF-SERVICE (DOS) PROTECTION HTTP AND HTTPS PING AND TRACEROUTE GREEN FEATURES: POWER SAVING BY CABLE LENGTH ( POWER SAVING WHEN LINK DOWN RFC 2131 DHCP CLIENT DHCP FILTERING IEEE 802.1X WITH GUEST VLAN JUMBO FRAME SUPPORT PORT-BASED SECURITY BY LOCKED MAC ADDRESSES MAC AND IP-BASED ACL STORM CONTROL FOR BROADCAST, MULTICAST AND UNKNOWN UNICAST PACKETS IGMP SNOOPING V1/V2 PORT-BASED EGRESS RATE LIMITING SNTP PORT MIRRORING SUPPORT (MANY-TO-ONE) WEB-BASED CONFIGURATION CONFIGURATION BACKUP/RESTORE PASSWORD ACCESS CONTROL TACACS AND RADIUS SUPPORT SYSLOG FIRMWARE UPGRADEABLE POE (46 WATTS OF POWER BUDGET)   SYSTEM REQUIREMENTS CATEGORY 5 NETWORK CABLES NETWORK CARD FOR EACH PC NETWORK SOFTWARE (E.G., MICROSOFT WINDOWS®) WEB BROWSER (E.G., INTERNET EXPLORER® 5.0 OR HIGHER, NETSCAPE® 6.0 OR HIGHER)   PACKAGE CONTENTS PROSAFE® 8-PORT GIGABIT POE SMART SWITCH WITH 2 GIGABIT FIBER SFP (GS110TP) AC ADAPTER RUBBER FOOTPADS WALL-MOUNT KIT RESOURCE CD INSTALLATION GUIDE GS110TP NETGEAR SWITCH PROSAFE 8 PORTAS GIGABIT TAGS DE GS110TP: GS110TP-300NAS, GS110TP, NETGEAR GS110TP, SWITCH NETGEAR GS110TP, SWITCH NETGEAR 8 PORTAS, SWITCH POE 8 PORTAS, SWITCH POE 8 PORTAS GIGABIT, SWITCH POE, POE 8PORTAS, NETGEAR PROSAFE, PROSAFE

Informações Adicionais
