Especificações Técnicas

3-V TO 5.5-V MULTICHANNEL RS-232 LINE DRIVER/RECEIVER WITH ±15-KV IEC ESD PROTECTION     FEATURES - SINGLE-CHIP AND SINGLE-SUPPLY INTERFACE FOR IBM- PC/AT- SERIAL PORT - ESD PROTECTION FOR RS-232 BUS PINS - ±15-KV HUMAN-BODY MODEL (HBM) - ±8-KV IEC61000-4-2, CONTACT DISCHARGE - ±15-KV IEC61000-4-2, AIR-GAP DISCHARGE - MEETS OR EXCEEDS REQUIREMENTS OF TIA/EIA-232-F AND ITU V.28 STANDARDS - OPERATES WITH 3-V TO 5.5-V VCC SUPPLY - ALWAYS-ACTIVE NONINVERTING RECEIVER OUTPUT (ROUT2B) - DESIGNED TO TRANSMIT AT A DATA RATE UP TO 500 KBIT/S - LOW STANDBY CURRENT . . . 1 -A TYP - EXTERNAL CAPACITORS . . . 4 × 0.1 -F - ACCEPTS 5-V LOGIC INPUT WITH 3.3-V SUPPLY - DESIGNED TO BE INTERCHANGEABLE WITH MAXIM MAX3243E - SERIAL-MOUSE DRIVEABILITY - AUTO-POWERDOWN FEATURE TO DISABLE DRIVER OUTPUTS WHEN NO VALID RS-232 SIGNAL IS SENSED - PACKAGE OPTIONS INCLUDE PLASTIC SMALL-OUTLINE (DW), SHRINK SMALL-OUTLINE (DB), AND THIN SHRINK SMALL-OUTLINE (PW) PACKAGES   APPLICATIONS - BATTERY-POWERED SYSTEMS - PDAS - NOTEBOOKS - LAPTOPS - PALMTOP PC - HAND-HELD EQUIPMENT MP243EI MULTICHANNEL RS-232 LINE DRIVER/RECEIVER TSSOP28 MAIORES DETALHES DE MP243EI NO SITE DO FABRICANTE: HTTPS://WWW.TI.COM/LIT/DS/SYMLINK/MAX3243E.PDF?TS=1648318082584&REF_URL=HTTPS%25 TAGS DE MP243EI: MAX3243EIPWR, MP243EI, MP243E, MP243, MAX3243EIPW, ICL3232, 3232ECBNZ, ICL3232ECBNZ-T, ICL3232ECBNZ, ICL3232E, L3232E, MAX3232, RS-232 INTERFACE IC, CI DRIVER RS232, CI DRIVER RS-232, CI MAX3232 SMD, CI DRIVER RS232 SMD, CI SMD MAX 3232, HIN202EIBN, HIN202EIBN-ND, IC TXRX RS-232 5V ESD 16-SOIC, RS-232 COMMUNICATIONS PORT, RS232, DRIVER RS232, DRIVER RS-232, CHIP RS-232, IC RS232, HIN202EIBN-T-ND, HIN202E, HIN206E, HIN207E, HIN208E, HIN211E, HIN213E, HIN232E, INTERSIL CORPORATION, SP3232EU, SP3232, SP3232EUCN, SP3232EUCN-L, SP3232EUCN-L/TR, HIN202EIBN, HIN202EIBN-ND, IC TXRX RS-232 5V ESD 16-SOIC, RS-232 COMMUNICATIONS PORT, RS232, DRIVER RS232, DRIVER RS-232, CHIP RS-232, IC RS232, HIN202EIBN-T-ND, HIN202E, HIN206E, HIN207E, HIN208E, HIN211E, HIN213E, HIN232E, INTERSIL CORPORATION, SP3232EBEY-L, SP3232EBEY, SP3232EBE
