Especificações Técnicas

ELECTRICAL SPECIFICATIONS INPUT RANGE: 100-240VAC AUTO RANGE , SINGLE PHASE FREQUENCY: 47-63HZ INPUT CURRENT: 7A MAX. @115VAC, 3.5A MAX. @230VAC, FULL LOAD INRUSH CURRENT; NOT EXCEED 60 AMPS PEAK AT 100 VRMS INPUT VOLTAGE, MEASURED AT COLD START EFFICIENCY: 63% MIN, AT LOW LINE 110/220 VAC FULL LOAD EMI/EMC: FCC PART 15J CLASS B, CISPR22/EMC DIRECTIVE 89/336 MAXIMUM POWER: 300 W MAX OUTPUT: 5V @ 31A, 12V @ 8A, 3.3V @ 12V, -5V @ 0.3A, -12V @ 0.4A, +5VSB @ 0.8A HOLD-UP TIME: 16MS MIN, AT MAXIMUM O-P (300W) 100V, 50HZ O/P RISE TIME: LESS THAN 100 MS (10% ~ 90% OF 0/P VOLTAGE) SHORT CIRCUIT PROTECTION: ALL OUTPUTS SHORT TO GROUND SHOULD NOT DAMAGE THE POWER SUPPLY OVER CURRENT PROTECTION: SINGLE POWER SUPPLY OPERATION LEAKAGE CURRENT: 0.75MA AT 100 VAC/60HZ POWER GOOD: THE UNIT HAS AN ACTIVE HIGH TTL COMPATIBLE SIGNAL CAPABLE OF SINKING 5MA AND SOURCING 200 UA. THIS SIGNAL BECOMES ACTIVE WITHIN 100 ~ 500 MS FROM +5V OUTPUT REACHING STEADY STATE. IT BECOME INACTIVE AT LEAST 1 MS BEFORE +5V DROP BELOW 4.75V OPERATION N TEMPERATURE: 5-40C STORAGE TEMPERATURE: -20-60C HUMIDITY: 5-95% RH CONNECTORS SUMMARY: 1X 20PIN MAIN CONNECTOR 1X 24PIN MAIN CONNECTOR 12X PERIPHERAL POWER CONNECTORS 2X FLOPPY POWER CONNECTORS 1X 6-PIN AUX POWER CONNECTOR 1X 10-PIN 3-WIRE SPECIAL CONNECTOR   DPS-300AB-1 FONTE REDUNDANTE DELTA ELECTRONICS 300 WATTS, PN: DP TAGS DE DPS-300AB-1: DPS-300AB-1, 300WATS, DELTA ELETRONICS, REDUNDANTE, FONTE REDUNDANTE, FONTE DELL, FONTE HP, FONTE HOT SWAP, FONTE IBM, FONTE PROLIANT, FONTE SERVER, FONTE DE ALIMENTAÇÃO, FONTE DE SERVIDOR, FONTE PARA SERVIDOR, DELTA ELETRONICS INC

Informações Adicionais
