Especificações Técnicas

OUTROS NUMEROS DE PEÇA PARA ESTE COMPONENTE: FSP250-50PLB FSP200-50PLA FSP180-50PLA FSP250-50GU SPI180LE FSP200-50PLAR-B DIMENSIONS: 150 X 81.5 X 40 MM CONNECTORS DETAILS: 2X MOLEX PERIPHERAL POWER CONNECTORS  LONGEST MOLEX LENGTH:480MM  4X SATA POWER CONNECTORS (ON 2 SEPARATE WIRES) LONGEST SATA LENGTH: 455MM 1X P4 4PIN POWER CONNECTOR LENGTH: 380MM 1X 20/24PIN MAIN POWER CONNECTOR TO SUPPORT BOTH 20PIN AND NEWER 24PIN MOTHERBOARDS CABLE E CONNECTOR LENGTH: 330MM     TECHNICAL  SPECIFICATIONS: HIGH EFFICIENCY: 70% MINIMUM AC INPUT (4763HZ) IS SWITCH SELECTABLE TO 115V (100127V) OR 230V (200240V). DC OUTPUT MAX LOAD: 200W 5V 3.3V 12V 12V 5VSB 7A 5A 11A 0.5A 2A 5% REGULATION  5% REGULATION 5% REGULATION 10% REGULATION 5% REGULATION RIPPLE: 50MV RIPPLE: 50MV RIPPLE: 150MV RIPPLE: 120MV RIPPLE: 100MV TRIPPLE PROTECTION:  OVERPOWER/ OVERVOLTAGE / SHORTCIRCUIT PROTECTION HIPOT TESTED: 1.5KV @ 10MA IS APPLIED FOR 60 SECONDS FOR EVERY UNIT TO TEST AC SURGE FAILURE PROTECTION.  ENVIRONMENT:                                                           OPERATING AMBIENT TEMPERATURE 5 TO 50                     OPERATING ENVIRONMENT RELATIVE HUMIDITY 20% TO 85%            OPERATING ALTITUDE: 0~10000 FEET                                      STORAGE AMBIENT TEMPERATURE 40 TO 55                     STORAGE ENVIRONMENT RELATIVE HUMIDITY 10% TO 95% FLEX1U-200 SHARK FONTE 1U ATX SLIM 200W TAGS DE FLEX1U-200: FLEX1U-200, 711797-101, 718785-001, DPS-300A B-83 A, FLEX1U200, FLEX 1U 200, FONTE 1U, DPS-250AB-24 B, DPS-250AB, DPS250, POWER SUPPLY 1U, MOLEX, SS-250SU, SS250SU, SS 250SU, SS-250, YM-5201D, YM5201D, FSP300-701UH, FSP300, PWS-351-1H, PWS351, PWS351-1H, 726704-001, DPS-345AB, P1M-6400P, FSP300-601U, P1A-6200P, KT-FATX250, SS250SU, FONTE 1U, FONTE SLIM, FONTE FLEX, FONTE PEQUENA, MICRO FONTE, FONTE MICRO, FONTE SEASONIC ATX 250W, FONTE ATX 250W SEASONIC, FSP250-50PLB FSP200-50PLA FSP180-50PLA FSP250-50GU SPI180LE FSP200-50PLAR-B, SB51G, SB51GB, SN41G2, SK41G, SB61G2, SS51G, SS51G1, SN41G2B, SS40G, SN45G, SK41GPFC, SS56G, SB62G2, SN85G, SS59, SS59GV2, SK43G, ST61G4, SB83G5, SB65G2, SB75G2, SK21G, SB52G2, SB83G5C, SB77G5, SS58G2, PS-X200W, PC40N250EV, PC34N220AC, PS-X160W, SS50C, SS30G, SB61G, SD30G2, PC50, PC40, PC60, WPOS-232, PC40I2503, FSP200-50PLA, FSP180-50PLA, FSP250-50PLB, FSP250-50GU, SPI180LE, FSP200-50PLAR-B, ENP-0616B, ENP-0616A, ENP-2320, ENP-2320A, ENP-2320B, ENP-2322A, ENP-2322B, FONTE SFX, MINI FONTE, FONTE SLIM, 200-WATT 1U FLEX ATX POWER SUPPLY, SHARK TECHNOLOGY
