Especificações Técnicas

FEATURES: IN ACCORDANCE WITH IPC 1U SPECIFICATIONS RATED 350W, PEAK 400W LOW NOISE, LOW RIPPLE, HIGH EFFICIENCY (MINIMUM 78%) BY O ~ 50°C  AMBIENT TEMPERATURE TEST PRODUCT SIZE: 200MM X 100MM X 40.5MM DOUBLE FAN: 4020MM DUAL BALL MUTE FAN LIFE CYCLE: = 100KH HOURS COMPLETE PROTECTION : OVER CURRENT, OVER VOLTAGE, UNDER VOLTAGE, OVER POWER, SHORT-CIRCUIT PROTECTION THE CERTIFICATION: CE, FCC OUTPUT INTERFACE: 20+4PIN 4+4PIN 5 PIN BIG 4 PIN MAIN POWER SUPPLY INTERFACE CPU INTERFACE SATA  INTERFACE PERIPHERAL EQUIPMENT INTERFACE 1 1 3 3 SPECIFICATIONS: MODEL NO TGC-SG1U400 TOTAL WATTAGE OUTPUT 350W EFFICIENCY > 78 % WHEN FULL LOAD P. G SIGNAL 100-500 MS HOLD-UP TIME 16MS MINIMUM NET WEIGHT 1.5 KG  THE APPEARANCE COLOR METALLIC SILVER(NATURAL METALLIC) FAN SIZE BALL-BEARING 4020*2 DIMENSION 200MM (L) X 100MM(W) X 40.5MM(H) PROTECTION OVER CURRENT PROTECTION, OVER VOLTAGE PROTECTION, UNDER VOLTAGE PROTECTION, OVER POWER PROTECTION, SHORT CIRCUIT PROTECTION  INPUT CHARACTERISTICS INPUT VOLTAGE RANGE 180-264VAC INPUT VOLTAGE FREQUENCY 47 ~ 63 HZ  LIFE CYCLE(MTBF) 100,000 HRS MINIMUM (AT 25 -) INPUT CURRENT 4A AT 220-230V OUTPUT CHARACTERISTICS VOLTAGE +5V +12V -12V +3.3V +5VSB MIN 1 0.5 0 0.5 0 NOM 8 11 0.25 9 1 MAX 16 22 0.5 18 2 UNITS AMPS AMPS AMPS AMPS AMPS 1) THE TOTAL OUTPUT POWER MUST NOT EXCEED 300W 2) +5V AND +3.3V TOTAL OUTPUT POWER MUST NOT EXCEED 120W 3) +5V, +3.3V, +12V TOTAL OUTPUT POWER MUST NOT EXCEED 285W WORKING ENVIRONMENT WORKING TEMPERATURE 0 °C TO 50 °C STORAGE TEMPERATURE -40 °C TO 80°C  OPERATING HUMIDITY 20% TO 85%, NON-CONDENSING STORAGE TEMPERATURE 10% TO 95%, NON-CONDENSING TGC-SG1U400S TGC FONTE 1U 350W REAIS 80 PLUS MAIORES DETALHES DE TGC-SG1U400S NO SITE DO FABRICANTE: HTTP://WWW.TGCIPC.COM/PT/PRODUCT.PHP?MOD=DETAIL&ID=42 TAGS DE TGC-SG1U400S: SG1U400S, KT-FATX250, TGC-SG1U400S, P1M-6400P, H1M-6607P, TC-1U40, H1U-6250P, PWS-281-1H, D41198-006, SS-250SU, TDPS-499AB A, MPW-6200F, FSP500-80BU, FONTE SLIM, FONTE FLEX, 80PLUS, TGC-14650-350, TGC-14650, FONTE CHASSI 1U, FONTE RACK 1U, FONTE PARA GABINETE 1U, AM630BS20S, 9TPWR2004A, FSP250-50GUB, CHASSIS 1U, GABINETE 1U
