Especificações Técnicas

32-BIT ARM PROCESSOR TO AUTOMATICALLY DETECT 10M/100M ETHERNET. SUPPORT ETHERNET, ARP, IP, UDP, TCP, ICMP PROTOCOL, SELECTABLE OPERATING MODES: TCP SERVER, TCP CLIENT, UDP SERVER, UDP CLIENT MODE, SUPPORT FOR INTER-GATEWAY, CROSS-ROUTING TRAFFIC.   FUNCTION: 100M HIGH-SPEED LAN, 10/100M ADAPTIVE ETHERNET INTERFACE; SUPPORT AUTO MDI / MDIX, USE CROSSOVER CABLE OR PARALLEL NETWORK CONNECTION; UART BAUD RATE FROM 1200 BPS TO 4.6 MBPS CAN BE SET; WORK TCP CLIENT, TCP SERVER, UDP MODE, ETC.; SUPPORTS VIRTUAL SERIAL PORT OPERATING MODE; ACROSS THE GATEWAY, ACROSS SWITCHES, ROUTERS; CAN WORK IN THE LAN, YOU CAN ALSO WORK ON THE INTERNET; WORKING PORT, DESTINATION IP ADDRESS AND PORT CAN BE EASILY SET UP THEIR OWN; (SETTINGS PROVIDED BY OUR SOFTWARE SETTINGS CAN ALSO BE ACCESSED VIA THE WEB SETTINGS) NETWORK IS DISCONNECTED AUTOMATICALLY DISCONNECTED, ENSURE THAT THE ENTIRE NETWORK AND RELIABLE TCP CONNECTION; FLEXIBLE SERIAL DATA SUB-FRAME IS SET TO MEET USER DEMAND FOR SUBCONTRACTING;   PARAMETER LAN ETHERNET: 10/100M BPS; PROTECTION: BUILT-5KV ELECTROMAGNETIC ISOLATION; UART SERIAL PORT * 1: TXD, RXD, GND; SERIAL BAUD RATE: BAUD RATE FROM 1200BPS TO 4.6MBPS CAN BE SET. NETWORK PROTOCOL: ETHERNET, ARP, IP, UDP, TCP, ICMP; TOOLS: MODULE CONFIGURATION SOFTWARE, TCP / UDP TEST TOOLS, SERIAL DEBUGGING SOFTWARE; CONFIGURATION: CABLE, SERIAL, IE PAGE; POWER SUPPLY: 5V, 500MA MECHANICAL PARAMETERS: MODULE SIZE (L * W) 80 * 50 (MM) THAT PCB SIZE; OPERATING TEMPERATURE: INDUSTRIAL GRADE -45 ~ 85 ° C PRESERVATION OF THE ENVIRONMENT: -40 ~ 85 ° C, 5 ~ 95% RH.   OPERING MODE TCP CLIENT TCP SERVER UDP UDP SERVER FB091A CONVERSOR RS232 RS485 PARA LAN RJ45 TAGS DE FB091A: FB091A, SERIAL LAN, LAN SERIAL, CONVERDOR RS232 LAN, RS232 RJ45, RS232 PARA LAN, RS232 RJ45, LAN PARA RS485, RS485 TO LAN, RS232 TO RS485, RS232 PARA RS485, RS-422, RS-232, RS-422, RS-485, RS422, HXSP-09F69, CONVERSOR RS232 RS485, RS232 RS485 TO TCP/IP, CONTROLADORA SERIAL, USR-TCP232-24, TCP232, OEM

Informações Adicionais
