Especificações Técnicas

  TYPE RECHARGEABLE  LITHIUM-ION MODEL LI-ION 9V-500MAH DIMENSION (48.5 -0.5)*(26.1 -0.2)*(15.4 -0.3)MM (MAX) C5MAH 500(MINI) C5MA 500MAH NOMINAL VOLTAGE 7.4V   CAPACITY   NOMINAL 500MAH MINIMUM 500MAH WHEN DISCHARGED AT 0.2C5MA TO 5.5V RECOMMENDED CHARGING CONDITIONS 0.2C5MA CHARGE TERMINATION CONTROL PARAMETERS TAPER CURRENT 0.01C5MA AT 8.4V SERVICE LIFE 1000CYCLES(>=60% C5MAH,0.2C DISCHARGE) WEIGHT CHARGING VOLTAGE 8.4 /-0.15V PROTECTION CIRCUIT MODULE OVER VOLTAGE LIMIT:      MIN 8.4V NORMAL 8.55V    MAX 8.7V UNDER VOLTAGE LIMIT:     MIN 5.00V NORMAL 5.15V    MAX 5.30V OVER CURRENT PROTECTION: MIN 0.12V NORMAL 0.15V    MAX 0.18V SHORT CIRCUIT TEST VOLTAGE:  MIN VDD-1.2V  NORMAL VDD-0.9V MAX VDD-0.6V MAX. QUIESCENT DRAIN:     0.1MA ESD PROTECTION:    10 KV INTERNAL RESISTANCE: 65 MILLIOHM (MAX)   AMBIENT TEMPERATURE RANGE CHARGING :  0-45 CENTIGRADE DISCHARGING:  -20 TO 60 CENTIGRADE STORAGE : -20 TO 40 CENTIGRADE LI-9V BATERIA RECARREGÁVEL 9V 500MAH E3 MAIORES DETALHES DE LI-9V NO SITE DO FABRICANTE: HTTP://WWW.SOSHINE.COM.CN/HTML/PRODUCTS467.HTM TAGS DE LI-9V: SC-V1, SCV1, 9V 6F22, 6F22, BATERIA 9V, BATERIA RECARREGAVEL, BATERIA DE 9V, 9V RECARREGÁVEL, E3, SOSHINE E3, BATERIA E3, 2SW00040, LI-9V, E3-SOSHINE, OEM, LI-9V
